Caterpillar D4 Crawler Tractor

Caterpillar D4 Crawler Tractor Specs front
Caterpillar D4 Crawler Tractor Specs front
Caterpillar D4 Crawler Tractor Specs side
Caterpillar D4 Crawler Tractor Specs side
Caterpillar D4 Crawler Tractor Specs back
Caterpillar D4 Crawler Tractor Specs back
Units

Dimensions

Dimensions

B

Width Over Tracks

6.5 ft in

C

Height to Top of Cab

5.75 ft in

D

Length of Track on Ground

5.17 ft in

E

Ground Clearance

0.95 ft in

F

Length w/o Blade

10.25 ft in

Undercarriage

G

Track Gauge

5 ft in

H

Standard Shoe Size

13 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2236

Gross Power

48 hp

Net Power

43 hp

Displacement

350 cu in

Aspiration

Natural

Operational

Operating Weight

10860 lb

Fuel Capacity

30 gal

Cooling System Fluid Capacity

11 gal

Engine Oil Capacity

3.8 gal

Powertrain Fluid Capacity

4.5 gal

Final Drives Fluid Capacity

1.8 gal

Transmission

Number of Forward Gears

5

Number of Reverse Gears

1

Max Speed - Forward

5.4 mph

Max Speed - Reverse

1.9 mph

Undercarriage

Ground Contact Area

1589 in2

Standard Shoe Size

13 in

Number of Shoes per Side

31

Track Gauge

5 ft in

Dimensions

Length w/o Blade

10.3 ft in

Width Over Tracks

6.5 ft in

Height to Top of Cab

5.8 ft in

Length of Track on Ground

5.2 ft in

Ground Clearance

1 ft in
