Caterpillar D3C LGP Series III Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
13.19ft in
B
Width Over Tracks
5.42ft in
C
Height To Top Of Cab
8.75ft in
D
Length Of Track On Ground
6.75ft in
E
Ground Clearance
0.99ft in
F
Length W/O Blade
9.79ft in
Bulldozer Blade Width - Straight
9.2ft in
Overall Height
8.75ft in
Undercarriage
G
Track Gauge
5.42ft in
H
Standard Shoe Size
25in
Number Of Track Rollers Per Side
6
Ground Pressure
4.16psi
Number Of Shoes Per Side
39
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
3046
Gross Power
78hp
Net Power
71hp
Power Measured @
2400rpm
Displacement
305cu in
Aspiration
Natural
Engine Model
Cat 3046
Power - Gross
78hp
Power - Net
70hp
Operational
Operating Weight
16842lb
Fuel Capacity
32gal
Cooling System Fluid Capacity
2.4gal
Engine Oil Capacity
3.5gal
Hydraulic Fluid Capacity
15.1gal
Powertrain Fluid Capacity
7.5gal
Final Drives Fluid Capacity
3.5gal
Operating Voltage
12V
Alternator Supplied Amperage
55amps
Transmission
Transmission Type
Powershift
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6.7mph
Max Speed - Reverse
7.1mph
Weights
Operating Weight - Xl
16842lb
Hydraulic System
Pump Type
Gear Style
Relief Valve Pressure
2500psi
Pump Flow Capacity
14.3gal/min
Standard Blade
Width
10.4ft in
Height
29.5in
Capacity
1.7yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
16.7in
Operating Specifications
Dig Depth - Vpat Blade
16in
Lift Height - Vpat Blade
30in
Maximum Tilt - Vpat Blade
19in
Maximum Angle - Vpat Blade
25degrees
