Caterpillar D10T Crawler Tractor

Caterpillar D10T Crawler Tractor Specs front
Caterpillar D10T Crawler Tractor Specs front
Caterpillar D10T Crawler Tractor Specs side
Caterpillar D10T Crawler Tractor Specs side
Caterpillar D10T Crawler Tractor Specs back
Caterpillar D10T Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

30.39 ft in

B

Width Over Tracks

10.4 ft in

C

Height to Top of Cab

13.4 ft in

D

Length of Track on Ground

12.67 ft in

E

Ground Clearance

2 ft in

F

Length w/o Blade

17.5 ft in

Undercarriage

H

Standard Shoe Size

24 in


Specifications

Engine

Number of Cylinders

12

Engine Make

2236

Engine Model

C27 ACERT

Gross Power

646 hp

Net Power

580 hp

Power Measured @

1800 rpm

Displacement

1647.5 cu in

Aspiration

Turbocharged

Operational

Operating Weight

146500 lb

Fuel Capacity

318 gal

Cooling System Fluid Capacity

34.9 gal

Engine Oil Capacity

18 gal

Hydraulic Fluid Capacity

38 gal

Powertrain Fluid Capacity

51 gal

Final Drives Fluid Capacity

6 gal

Operating Voltage

24 V

Alternator Supplied Amperage

95 amps

Transmission

Transmission Type

Powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

7.9 mph

Max Speed - Reverse

9.8 mph

Undercarriage

Ground Contact Area

7326 in2

Standard Shoe Size

24 in

Number of Shoes per Side

44

Number of Track Rollers per Side

8

Track Pitch

10.2 in

Hydraulic System

Pump type

gear driven

Relief Valve Pressure

2725 psi

Pump Flow Capacity

107 gal/min

Standard Blade

Width

15.9 ft in

Height

81 in

Capacity

24.2 yd3

Cutting Depth

26.5 in

Dimensions

Length w/o Blade

17.5 ft in

Length w/ Blade

30.4 ft in

Width Over Tracks

10.4 ft in

Height to Top of Cab

13.4 ft in

Length of Track on Ground

12.7 ft in

Ground Clearance

2 ft in
