Caterpillar CW14 Compactor
Units
Dimensions
Dimensions
E
Ground Clearance
10.5ft in
Overall Length
1.18ft in
Height - Rops
0.82ft in
Height - Steering Wheel
91in
Maximum Machine Height
9.81in
Operating Specifications
E
Ground Clearance
0.88ft in
Compaction Width
68in
Turning Radius - Outside
21.1in
Number Of Wheels
9 or 11
Rolling Width
68in
Travel Speed - Maximum
11mph
Turning Radius - Inside (1)
15.1in
Turning Radius - Inside (2)
15.1ft in
Specifications
Engine
Engine Make
2236
Engine Model
C3.4B
Gross Power
100.5hp
Bore
3.9in
Stroke
4.4in
Engine Model
C3.4B
Operational
Fuel Capacity
45.6gal
Transmission
Max Speed
11mph
Tires
Tires
7.5 x 15
Weights
Operating Weight - No Ballast
10770lb
Average Weight Per Wheel - No Ballast
1190lb
Average Weight Per Wheel - Maximum Ballast
1212lb
Operating Weight - Maximum Ballast
28528lb
Operating Weight - Standard Machine Empty
10770lb
Operating Weight - Maximum Water Ballast
19202lb
Operating Weight - Maximum Wet Sand Ballast
28528lb
Average Weight Per Wheel
2116lb
Operating Weight - Maximum Ballast, Hw Option
38000lb
Average Weight Per Wheel - Maximum Ballast, Hw Option
4233lb
Operating Weight - Without Ballast - Heavy Weight Option
10924lb
Operating Weight - With Maximum Ballast - Heavy Weight Option
38000lb
Operating Weight - Per Wheel - Heavy Weight Option
4233lb
Service Refill Capacities
Fuel Tank Capacity
45.6gal
Water Spray Tank Capacity
104gal
