Caterpillar BG245C Asphalt Paver

Caterpillar BG245C Asphalt Paver Specs front
Caterpillar BG245C Asphalt Paver Specs front
Caterpillar BG245C Asphalt Paver Specs side
Caterpillar BG245C Asphalt Paver Specs side
Caterpillar BG245C Asphalt Paver Specs back
Caterpillar BG245C Asphalt Paver Specs back
Units

Dimensions

Dimensions

A

Length w/ Screed

21.59 ft in

B

Transport Width

10 ft in

C

Transport Height

9.09 ft in

D

Length of Track on Ground

8.92 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

3116TA

Gross Power

174 hp

Power Measured @

2200 rpm

Displacement

402.8 cu in

Operational

Operating Weight w/o Screed

34304 lb

Fuel Capacity

60 gal

Hydraulic System Fluid Capacity

40 gal

Cooling System Fluid Capacity

8.4 gal

Hopper/Paver

Hopper Capacity

8 lb

Paving Width - std

8 ft in

Paving Width - max

30 ft in

Paving Speed - max

215.3 ft/min

Travel Speed - max

5 mph

Auger Diameter

17.6 in

Dimensions

Length w/ Screed

21.6 ft in

Transport Width

10 ft in

Transport Height

9.1 ft in

Length of Track on Ground

9 ft in

Track Width

14.1 in
