Caterpillar BG240B Asphalt Paver

Caterpillar BG240B Asphalt Paver Specs front
Caterpillar BG240B Asphalt Paver Specs front
Caterpillar BG240B Asphalt Paver Specs side
Caterpillar BG240B Asphalt Paver Specs side
Caterpillar BG240B Asphalt Paver Specs back
Caterpillar BG240B Asphalt Paver Specs back
Units

Dimensions

Dimensions

A

Length w/ Screed

22.09 ft in

B

Transport Width

10 ft in


Specifications

Engine

Engine Model

JD4045T

Gross Power

115 hp

Displacement

274.7 cu in

Operational

Operating Weight w/o Screed

26226.2 lb

Fuel Capacity

41.5 gal

Hydraulic System Fluid Capacity

42.1 gal

Cooling System Fluid Capacity

9.3 gal

Hopper/Paver

Paving Width - std

8 ft in

Paving Width - max

20 ft in

Paving Speed - max

265.1 ft/min

Travel Speed - max

10.4 mph

Auger Diameter

16 in

Dimensions

Length w/ Screed

22.1 ft in

Transport Width

10 ft in

Tire Size

16x22 Solid Rubber, 16x24


Compare similar models

Manufacturer / Model

Operating Weight w/o Screed

Paving Width - max

Operating Weight w/o Screed

25992.6 lb

Paving Width - max

20 ft in

Operating Weight w/o Screed

25992.6 lb

Paving Width - max

20 ft in

Operating Weight w/o Screed

26900.9 lb

Paving Width - max

20 ft in
