Caterpillar 980G Wheel Loader

Caterpillar 980G Wheel Loader Specs front
Caterpillar 980G Wheel Loader Specs front
Caterpillar 980G Wheel Loader Specs side
Caterpillar 980G Wheel Loader Specs side
Caterpillar 980G Wheel Loader Specs back
Caterpillar 980G Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

10.74 ft in

Dimensions

A

Length with Bucket on Ground

31.06 ft in

B

Width Over Tires

10.67 ft in

C

Height to Top of Cab

12.31 ft in

E

Ground Clearance

1.54 ft in

H

Reach at Max Lift and Dump

5.07 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3406DITA

Net Power

323 hp

Gross Power

300 hp

Displacement

891 cu in

Operational

Operating Weight

65638.3 lb

Fuel Capacity

124.2 gal

Hydraulic System Fluid Capacity

55 gal

Engine Oil Fluid Capacity

10 gal

Static Tipping Weight

44767.1 lb

Transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

23.3 mph

Max Speed - Reverse

26.6 mph

Hydraulic System

Raise Time

6 sec

Dump Time

2 sec

Lower Time

3.4 sec

Bucket

Breakout Force

47277 lb

Dump Clearance at Max Raise

10.8 ft in

Bucket Width

11.4 ft in

Bucket Capacity - heaped

5.5 yd3

Dimensions

Length with Bucket on Ground

31.1 ft in

Width Over Tires

10.7 ft in

Height to Top of Cab

12.4 ft in

Ground Clearance

1.6 ft in

Reach at Max Lift and Dump

5.1 ft in


Compare similar models

Manufacturer / Model

Gross Power

Operating Weight

Bucket Capacity - heaped

Gross Power

322 hp

Operating Weight

63411.6 lb

Bucket Capacity - heaped

5.3 yd3

Gross Power

335 hp

Operating Weight

67020 lb

Bucket Capacity - heaped

5.7 yd3

Gross Power

335 hp

Operating Weight

63753 lb

Bucket Capacity - heaped

5.5 yd3
