Caterpillar 966D Wheel Loader

Caterpillar 966D Wheel Loader Specs front
Caterpillar 966D Wheel Loader Specs front
Caterpillar 966D Wheel Loader Specs side
Caterpillar 966D Wheel Loader Specs side
Caterpillar 966D Wheel Loader Specs back
Caterpillar 966D Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.91 ft in

Dimensions

A

Length with Bucket on Ground

25.64 ft in

B

Width Over Tires

9.4 ft in

C

Height to Top of Cab

11.68 ft in

D

Wheelbase

11 ft in

E

Ground Clearance

1.48 ft in

F

Hinge Pin - Max Height

1.84 ft in

H

Reach at Max Lift and Dump

3.58 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3306

Net Power

199.9 hp

Displacement

640.8 cu in

Operational

Operating Weight

43001.2 lb

Fuel Capacity

81.4 gal

Hydraulic System Fluid Capacity

60.8 gal

Static Tipping Weight

30366.5 lb

Turning Radius

24.1 ft in

Transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

21.4 mph

Max Speed - Reverse

23.7 mph

Hydraulic System

Raise Time

6.3 sec

Dump Time

2 sec

Lower Time

3 sec

Bucket

Breakout Force

Dump Clearance at Max Raise

10 ft in

Bucket Width

10 ft in

Bucket Capacity - heaped

4.1 yd3

Bucket Capacity - struck

3.5 yd3

Dimensions

Length with Bucket on Ground

25.7 ft in

Width Over Tires

9.4 ft in

Height to Top of Cab

11.7 ft in

Ground Clearance

1.5 ft in

Wheelbase

11 ft in

Hinge Pin - Max Height

1.9 ft in

Reach at Max Lift and Dump

3.6 ft in
