Caterpillar 924H Integrated Tool Carrier

Caterpillar 924H Integrated Tool Carrier Specs front
Caterpillar 924H Integrated Tool Carrier Specs front
Caterpillar 924H Integrated Tool Carrier Specs extended_1
Caterpillar 924H Integrated Tool Carrier Specs extended_1
Caterpillar 924H Integrated Tool Carrier Specs extended_2
Caterpillar 924H Integrated Tool Carrier Specs extended_2
Caterpillar 924H Integrated Tool Carrier Specs extended_3
Caterpillar 924H Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

23.45 ft in

B

Width Over Tires

8.18 ft in

C

Height to Top of Cab

10.59 ft in

D

Wheelbase

9.19 ft in

E

Ground Clearance

1.44 ft in

F

Hinge Pin Max Height

12.75 ft in

G

Dump Clearance at Max Lift

9.28 ft in

I

Fork Tine Length

4.01 ft in

K

Max Lift Height

11.94 ft in


Specifications

Engine

Engine Make

2236

Engine Model

C6.6

Net Power

138 hp

Max Torque

496 lb ft

Displacement

403

Operational

Operating Weight

25644.2 lb

Fuel Capacity

59.5 gal

Cooling System Fluid Capacity

10.6 gal

Engine Oil Capacity

4 gal

Transmission Fluid Capacity

6.1 gal

Front Diff Fluid Capacity

5.6 gal

Rear Diff Fluid Capacity

5.6 gal

Hydraulic System Fluid Capacity

39.1 gal

Turning Radius

18.5 ft in

Static Tipping Load - Bucket

17916 lb

Static Tipping Load - Forks

13669 lb

Tire Size

20.5R25 Radial (L-3)

Transmission

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed Forward

23.9 mph

Max Speed Reverse

13.5 mph

Hydraulic System

Relief Valve Setting

3755

Pump Flow Capacity

39.5 gal/min

Raise Time

5.1 sec

Dump Time

1.4 sec

Lower Time

2.4 sec

Bucket

Breakout Force

19848 lb

Bucket Capacity - heaped

2.7 yd3

Bucket Capacity - struck

2.2 yd3

Dimensions

Width Over Tires

8.2 ft in

Height to Top of Cab

10.6 ft in

Wheelbase

9.2 ft in

Ground Clearance

1.5 ft in

Hinge Pin Max Height

12.8 ft in

Length w/ Bucket on Ground

23.5 ft in

Dump Clearance at Max Lift

9.3 ft in

Reach at Max Height and Dump

3.3 ft in

Fork Tine Length

4.1 ft in

Length with out Forks on Ground

25 ft in

Max Lift Height

12 ft in
