Caterpillar 633E Series II Motor Scraper

Caterpillar 633E Series II Motor Scraper Specs front
Caterpillar 633E Series II Motor Scraper Specs front
Caterpillar 633E Series II Motor Scraper Specs side
Caterpillar 633E Series II Motor Scraper Specs side
Caterpillar 633E Series II Motor Scraper Specs back
Caterpillar 633E Series II Motor Scraper Specs back
Units

Dimensions

Dimensions

A

Overall Length

48.56 ft in

B

Overall Width

13 ft in

C

Overall Height

13.92 ft in

D

Wheelbase

29.6 ft in


Specifications

Tractor Engine

Model

3408TA

Gross Power

490 hp

Net Power

450 hp

Displacement

1098.5 cu in

Scraper Engine

Displacement

49673.4 cu in

Transmission

Max Speed Forward

33 mph

Weights

Total Operating - empty

112678.3 lb

Bowl

Rated Payload

82012 lb

Heaped Capacity

34.1 yd3

Struck Capacity

23.2 yd3

Max Depth of Cut

24.1 in

Width of Cut

11.5 ft in

Dimensions

Overall Length

48.6 ft in

Overall Width

13 ft in

Overall Height

14 ft in

Wheelbase

29.6 ft in
