Caterpillar 552 Feller Buncher

Units

Dimensions

Dimensions

A

Overall Length

30.92 ft in

B

Overall Width

10.92 ft in

C

Height to Top of Cab

13 ft in

E

Ground Clearance

2.92 in

Undercarriage

F

Track Gauge

8.51 ft in

G

Shoe Size

28 in


Specifications

Engine

Engine Make

2236

Engine Model

C9 ACERT

Gross Power

305 hp

Net Power

282 hp

Power Measured @

2100 rpm

Displacement

537.1

Operational

Operating Weight w/o Attachment

78661 lb

Fuel Capacity

312 gal

Cooling System Fluid Capacity

16.2 gal

Engine Oil Capacity

10.4 gal

Hydraulic System Fluid Capacity

97.8 gal

Operating Voltage

24 V

Alternator Supplied Amperage

95 amps

Undercarriage

Track Pitch

8.5 in

Shoe Size

28 in

Tractive Effort

104000.9 lb

Track Gauge

8.6 ft in

Upperstructure Leveling

Front

20 degrees

Side

11 degrees

Boom

Bare Pin Lift at Max Reach

20723.5 lb

Dimensions

Ground Clearance

3 in

Overall Length

31 ft in

Overall Width

11 ft in

Height to Top of Cab

13 ft in

Max Reach

28.3 ft in
