Caterpillar 545C Grapple Skidder

Caterpillar 545C Grapple Skidder Specs front
Caterpillar 545C Grapple Skidder Specs front
Caterpillar 545C Grapple Skidder Specs back
Caterpillar 545C Grapple Skidder Specs back
Caterpillar 545C Grapple Skidder Specs extended
Caterpillar 545C Grapple Skidder Specs extended
Units

Dimensions

Dimensions

A

Overall Length

26.34 ft in

A

Overall Length

- -

B

Overall Width

11.15 ft in

C

Height to Top of Cab

10.45 ft in

D

Wheelbase

12.93 ft in

E

Ground Clearance

1.75 ft in

F

Max Height of Boom

14.12 ft in

G

Height of Grapple from Ground

- -

H

Reach of Grapple at Ground Level

- -

I

Tong Opening at Tips

10.59 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

C7 Acert

Gross Power

232 hp

Net Power

219 hp

Power Measured @

1800 rpm

Peak Torque

701.5 lb ft

Torque Measured @

1400 rpm

Displacement

439 cu in

Operational

Operating Weight

42325 lb

Fuel Capacity

99.8 gal

Cooling System Fluid Capacity

15 gal

Engine Oil Capacity

7.1 gal

Front Diff Fluid Capacity

13.7 gal

Rear Diff Fluid Capacity

19.5 gal

Transmission Fluid Capacity

14.2 gal

Hydraulic System Fluid Capacity

29.6 gal

Operational Voltage

24 V

Alternator Supplied Amperage

80 amps

Steering Angle

45 degrees

Tire Size

30.5x 32 16PR

Transmission

Transmission Type

Countershaft powershift

Number of Forward Gears

5

Number of Reverse Gears

3

Max Speed - Forward

17.1 mph

Max Speed - Reverse

11.6 mph

Hydraulic

Pump Type

Piston pump, variable displacement

Pump Flow

50 gal/min

Relief Valve Pressure

3045 psi

Dimensions

Overall Width

11.2 ft in

Blade Width

10.3 ft in

Height to Top of Cab

10.5 ft in

Max Blade Height

54.4 in

Wheelbase

13 ft in

Ground Clearance

1.8 ft in

Overall Length

26.4 ft in

Max Height of Boom

14.2 ft in

Tong Opening at Tips

10.6 in

Grapple Capacity - tongs tip to tip

16.6 ft2

Drum Diameter

0.8 in

Cable Width

0.8 in

Drum Capacity at Cable Width

154 ft in

Max Line Pull - bare drum

39342 lb

Max Line Speed

132 ft/min
