Caterpillar 385B L Hydraulic Excavator
Units
Dimensions
Undercarriage
N
Shoe Size
30in
Drawbar Pull
133030lb
Max Travel Speed
2.8mph
Number Of Carrier Rollers Per Side
3
Number Of Shoes Per Side
47
Number Of Track Rollers Per Side
8
Specifications
Engine
Engine Model
Caterpillar 3456 ATAAC
Net Power
513hp
Displacement
964cu in
Bore
5.6in
Stroke
6.8in
Net Power - Iso 9249
513hp
Net Power - Sae J1349
513hp
Engine Model
Caterpillar 3456 ATAAC
Net Power - Eec 80/1269
513hp
Net Flywheel Power
513hp
Operational
Fuel Capacity
328gal
Cooling System Fluid Capacity
26.7gal
Engine Oil Capacity
21.1gal
Swing Drive Fluid Capacity
5gal
Swing Mechanism
Swing Torque
191770lb ft
Swing Speed
6.2rpm
Weights
Operating Weight - Long Undercarriage
189770lb
Operating Weight - Standard Undercarriage
183940lb
Hydraulic System
Pilot System - Maximum Flow
23.8 gal/min
Pilot System - Maximum Pressure
595 psi
Maximum Pressure - Travel
5075 psi
Maximum Pressure - Swing
3770 psi
Swing System - Maximum Flow
119 gal/min
Boom Cylinder - Bore
8.3in
Boom Cylinder - Stroke
77.4in
Stick Cylinder - Bore
8.7in
Stick Cylinder - Stroke
89.1in
Main System - Maximum Flow - Total
258 gal/min
Maximum Pressure - Equipment - Heavy Lift
5075 psi
Maximum Pressure - Equipment - Normal
4640 psi
Hb Family Bucket Cylinder - Bore
7.9in
Hb Family Bucket Cylinder - Stroke
57.1in
Jb Family Bucket Cylinder - Stroke
62.4in
Jb Family Bucket Cylinder - Bore
8.7in
Operating Specifications
Maximum Reach - Ground Level
51.6ft in
Maximum Digging Depth
35.1ft in
Service Refill Capacities
Cooling System
26.7gal
Final Drive - Each
5.5gal
Hydraulic Tank
214gal
Hydraulic System - Including Tank
263gal
Engine Oil
21.1gal
Fuel Tank Capacity
328gal
Swing Drive - Each
5gal
Standards
Brakes
SAE J1026 APR 90
Cab/Fogs
SAE J1356 FEB 88 ISO 10262
Sound Performance
Performance
ANSI/SAE J1166 OCT 98
Track
Number Of Carrier Rollers - Each Side
3
Number Of Track Rollers - Each Side - Long Undercarriage
9
Number Of Shoes - Each Side - Long Undercarriage
51
Standard With Long Undercarriage
36in
Optional For Long Undercarriage
30in
Number Of Shoes - Each Side - Standard Undercarriage
47
Number Of Track Rollers - Each Side - Standard Undercarriage
8
Standard With Standard Length Undercarriage
30in
Optional For Standard Length Undercarriage
36in
Drive
Maximum Travel Speed
2.8mph
Maximum Drawbar Pull - Long Undercarriage
132810lb
Maximum Drawbar Pull - Standard Undercarriage
133030lb
