Caterpillar 345C MH Material Handler
Units
Dimensions
Dimensions
E
Ground Clearance
2.4ft in
A
Shipping Length
45.5ft in
Operating Height - To Top Of Cab (Fixed)
17.8ft in
Operating Width
14.65ft in
Counterweight Clearance
4.8ft in
Height - Top Of Exhaust
11.8ft in
Rear - Carrier To End Of Boom
45.48ft in
Shipping Height - Cab Tipped
11.83ft in
Shipping Width
13.1ft in
Tail Swing Radius
12.3ft in
Track
Gauge
146 lb/in
Overall Track Length
17.61in
Track Shoes
30 lb/in
Rollers - Each Side
9
Shoes Per Side
52
Specifications
Engine
Displacement
763cu in
Bore
5.1in
Stroke
6.2in
Net Power - Iso 9249
345hp
Net Power - Sae J1349
345hp
Engine Model
Cat C13 ACERT
Net Power - Eec 80/1269
345hp
Net Flywheel Power
345hp
Performance
Maximum Drawbar Pull
74411.8lb
Swing Mechanism
Swing Speed
8.6rpm
Swing Torque
109900lb ft
Weights
Operating Weight
126615 lb
Upper
34390lb
Counterweight
26455lb
Undercarriage - Including Carbody
46690lb
Two-Piece Front - With Cylinders
19080lb
Stick
6034lb
Hydraulic System
Pilot System - Maximum Flow
11.36 gal/min
Pilot System - Maximum Pressure
596 psi
Maximum Pressure - Travel
4982 psi
Maximum Pressure - Swing
4554 psi
Maximum Flow - Each Of Two Pumps
95 gal/min
Maximum Pressure - Implements
4982 psi
Rotate Circuit For Grapple Maximum Flow
11 gal/min
Generator Auxiliary Pump Maximum Flow
43 gal/min
Generator Auxiliary Pump Maximum Pressure
4000 psi
Rotate Circuit For Grapple Operating Pressure
4000 psi
Brakes
Brake Standards
Meets the following standards: SAE J1026 APR90
Operating Specifications
Maximum Reach
59
Generator Set
33.5hp
Cab Riser - Fixed
6.5ft in
Service Refill Capacities
Cooling System
16gal
Fuel Tank
186gal
Final Drive - Each
4gal
Hydraulic Tank
64gal
Hydraulic System - Including Tank
150gal
Engine Oil
11.6gal
Swing Drive
2.6gal
Cab
Cab/Fogs Standards
Optional operator protection guards meeting SAE J1356 and ISO 3449.
Drive
Maximum Travel Speed
2.7mph
Maximum Drawbar Pull
74380lb
