Caterpillar 345B L-VG Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
38.52ft in
C
Shipping Height Of Unit
12.08ft in
J
Max Loading Height
25.27ft in
K
Max Reach Along Ground
42.56ft in
L
Max Vertical Wall Digging Depth
23.36ft in
M
Max Digging Depth
29.89ft in
Boom/Stick Option (Hex) 1
reach boom w/ stick 4800mm
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
38.52ft in
I
Max Cutting Height
36.03ft in
C
Shipping Height Of Unit
12.08ft in
J
Max Loading Height
24.64ft in
K
Max Reach Along Ground
39.93ft in
L
Max Vertical Wall Digging Depth
20.87ft in
M
Max Digging Depth
26.65ft in
Boom/Stick Option (Hex) 2
reach boom w/ stick 3900mm
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
38.52ft in
I
Max Cutting Height
35.9ft in
J
Max Loading Height
24.74ft in
C
Shipping Height Of Unit
12.08ft in
K
Max Reach Along Ground
38.33ft in
L
Max Vertical Wall Digging Depth
19.76ft in
M
Max Digging Depth
24.64ft in
Boom/Stick Option (Hex) 3
reach boom w/ stick 3350mm
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
35.31ft in
C
Shipping Height Of Unit
11.68ft in
I
Max Cutting Height
34.49ft in
J
Max Loading Height
23ft in
K
Max Reach Along Ground
36.39ft in
M
Max Digging Depth
23.04ft in
Max Vertical Wall Dig Depth
17.36ft in
Boom/Stick Option (Hex) 4
mass boom w/ stick 3000mm
Dimensions
E
Ground Clearance
2.43ft in
G
Height To Top Of Cab
10.98ft in
B
Width To Outside Of Tracks
9.81ft in
D
Length Of Track On Ground
14.24ft in
H
Tail Swing Radius
11.85ft in
Removal Counterweight Clearance
4.79ft in
Undercarriage
F
Track Gauge
8.99ft in
N
Shoe Size
29.53in
Drawbar Pull
72400lb
Max Travel Speed
2.74mph
Specifications
Engine
Engine Model
3176CATAAC
Gross Power
290hp
Displacement
628.6cu in
Operational
Operating Weight
101853.6lb
Fuel Capacity
158.6gal
Hydraulic System Relief Valve Pressure
4980psi
Hydraulic Pump Flow Capacity
169.1gal/min
