Caterpillar 336EL Hydraulic Excavator

Caterpillar 336EL Hydraulic Excavator Specs front
Caterpillar 336EL Hydraulic Excavator Specs front
Caterpillar 336EL Hydraulic Excavator Specs side
Caterpillar 336EL Hydraulic Excavator Specs side
Caterpillar 336EL Hydraulic Excavator Specs extended
Caterpillar 336EL Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

36.65 ft in

C

Shipping Height of Unit

12.01 ft in

I

Max Cutting Height

35.24 ft in

J

Max Loading Height

6.27 ft in

K

Max Reach Along Ground

38.46 ft in

L

Max Vertical Wall Digging Depth

20.71 ft in

M

Max Digging Depth

26.88 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

36.62 ft in

C

Shipping Height of Unit

11.52 ft in

I

Max Cutting Height

33.86 ft in

J

Max Loading Height

8.57 ft in

K

Max Reach Along Ground

36.16 ft in

L

Max Vertical Wall Digging Depth

18.05 ft in

M

Max Digging Depth

24.58 ft in

Boom/Stick Option (HEX) 3

A

Shipping Length of Unit

35.73 ft in

C

Shipping Height of Unit

11.82 ft in

I

Max Cutting Height

32.71 ft in

J

Max Loading Height

21.72 ft in

K

Max Reach Along Ground

33.67 ft in

L

Max Vertical Wall Digging Depth

14.6 ft in

M

Max Digging Depth

21.82 ft in

Dimensions

B

Width to Outside of Tracks

11.13 ft in

D

Length of Track on Ground

13.26 ft in

E

Ground Clearance

1.68 ft in

G

Height to Top of Cab

10.34 ft in

H

Tail Swing Radius

11.49 ft in

Undercarriage

F

Track Gauge

8.5 ft in

N

Shoe Size

31.5 in


Specifications

Engine

Engine Make

2236

Engine Model

C9.3

Gross Power

323.2 hp

Net Power

300.4 hp

Displacement

568 cu in

Operational

Operating Weight

67236.6 lb

Fuel Capacity

163.8 gal

Cooling System Fluid Capacity

14.8 gal

Hydraulic System Fluid Capacity

100.4 gal

Engine Oil Capacity

8.1 gal

Swing Drive Fluid Capacity

5 gal

Hydraulic System Relief Valve Pressure

5076 psi

Hydraulic Pump Flow Capacity

74 gal/min

Swing Mechanism

Swing Speed

9.2 rpm

Swing Torque

80400 lb ft

Undercarriage

Shoe Size

31.5 in

Max Travel Speed

1.9 mph

Drawbar Pull

66318.7 lb

Track Gauge

8.5 ft in

Buckets

Reference Bucket Capacity

1.6 yd3

Minimum Bucket Capacity

1.3 yd3

Maximum Bucket Capacity

3.4 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom (21\\\\\\\'4\\\\\\\'\\\\\\\') Stick (12\\\\\\\'10\\\\\\\'\\\\\\\')

Shipping Height of Unit

12.1 ft in

Shipping Length of Unit

36.7 ft in

Max Digging Depth

26.9 ft in

Max Reach Along Ground

38.5 ft in

Max Cutting Height

35.3 ft in

Max Loading Height

6.3 ft in

Max Vertical Wall Digging Depth

20.8 ft in

Boom/Stick Option (HEX) 2

Shipping Height of Unit

11.6 ft in

Shipping Length of Unit

36.7 ft in

Max Digging Depth

24.6 ft in

Max Reach Along Ground

36.2 ft in

Max Cutting Height

33.9 ft in

Max Loading Height

8.6 ft in

Max Vertical Wall Digging Depth

18.1 ft in

Boom/Stick Option (HEX) 3

Shipping Height of Unit

11.9 ft in

Shipping Length of Unit

35.8 ft in

Max Digging Depth

21.9 ft in

Max Reach Along Ground

33.7 ft in

Max Cutting Height

32.8 ft in

Max Loading Height

21.8 ft in

Max Vertical Wall Digging Depth

14.6 ft in

Dimensions

Width to Outside of Tracks

11.2 ft in

Height to Top of Cab

10.4 ft in

Ground Clearance

1.7 ft in

Removal Counterweight Clearance

4.1 ft in

Tail Swing Radius

11.5 ft in

Length of Track on Ground

13.3 ft in
