Caterpillar 329D L Hydraulic Excavator

Caterpillar 329D L Hydraulic Excavator Specs front
Caterpillar 329D L Hydraulic Excavator Specs front
Caterpillar 329D L Hydraulic Excavator Specs side
Caterpillar 329D L Hydraulic Excavator Specs side
Caterpillar 329D L Hydraulic Excavator Specs extended
Caterpillar 329D L Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

34.16 ft in

C

Shipping Height of Unit

11.92 ft in

I

Max Cutting Height

33.79 ft in

J

Max Loading Height

23.31 ft in

K

Max Reach Along Ground

36.6 ft in

L

Max Vertical Wall Digging Depth

21.63 ft in

M

Max Digging Depth

25.7 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

34.16 ft in

C

Shipping Height of Unit

10.44 ft in

I

Max Cutting Height

33.19 ft in

J

Max Loading Height

22.67 ft in

K

Max Reach Along Ground

34.97 ft in

L

Max Vertical Wall Digging Depth

20.16 ft in

M

Max Digging Depth

23.9 ft in

Boom/Stick Option (HEX) 3

A

Shipping Length of Unit

34.19 ft in

C

Shipping Height of Unit

10.47 ft in

I

Max Cutting Height

32.81 ft in

J

Max Loading Height

22.19 ft in

K

Max Reach Along Ground

33.39 ft in

L

Max Vertical Wall Digging Depth

19.07 ft in

M

Max Digging Depth

22.09 ft in

Boom/Stick Option (HEX) 4

A

Shipping Length of Unit

32.16 ft in

C

Shipping Height of Unit

10.27 ft in

I

Max Cutting Height

31.78 ft in

J

Max Loading Height

21.26 ft in

K

Max Reach Along Ground

32.89 ft in

M

Max Digging Depth

22.11 ft in

Boom/Stick Option (HEX) 5

A

Shipping Length of Unit

32.35 ft in

C

Shipping Height of Unit

10.67 ft in

I

Max Cutting Height

30.28 ft in

J

Max Loading Height

19.64 ft in

K

Max Reach Along Ground

31.02 ft in

M

Max Digging Depth

20.12 ft in

Dimensions

B

Width to Outside of Tracks

11.13 ft in

D

Length of Track on Ground

13.1 ft in

E

Ground Clearance

1.61 ft in

G

Height to Top of Cab

9.98 ft in

H

Tail Swing Radius

10.11 ft in

Undercarriage

F

Track Gauge

17.36 ft in

N

Shoe Size

31.5 in


Specifications

Engine

Engine Make

2236

Engine Model

C7 ACERT

Net Power

202 hp

Displacement

439.4 cu in

Operational

Operating Weight

64463.2 lb

Fuel Capacity

137.4 gal

Cooling System Fluid Capacity

8 gal

Hydraulic System Fluid Capacity

81.9 gal

Engine Oil Capacity

8 gal

Swing Drive Fluid Capacity

2.7 gal

Hydraulic System Relief Valve Pressure

5076.4 psi

Hydraulic Pump Flow Capacity

62.1 gal/min

Swing Mechanism

Swing Speed

10.2 rpm

Swing Torque

60628 lb ft

Undercarriage

Number of Shoes per Side

50

Shoe Size

31.5 in

Number of Carrier Rollers per Side

2

Number of Track Rollers per Side

9

Max Travel Speed

3.3 mph

Drawbar Pull

55977.5 lb

Track Gauge

17.4 ft in

Buckets

Reference Bucket Capacity

1.5 yd3

Minimum Bucket Capacity

1.3 yd3

Maximum Bucket Capacity

3.4 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 6150mm (20\' 2\'\') / Stick 12\' 4\'\'

Shipping Height of Unit

12 ft in

Shipping Length of Unit

34.2 ft in

Max Digging Depth

25.7 ft in

Max Reach Along Ground

36.6 ft in

Max Cutting Height

33.8 ft in

Max Loading Height

23.4 ft in

Max Vertical Wall Digging Depth

21.7 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 6150mm (20\' 2\'\') / Stick 10\' 6\'\'

Shipping Height of Unit

10.5 ft in

Shipping Length of Unit

34.2 ft in

Max Digging Depth

23.9 ft in

Max Reach Along Ground

35 ft in

Max Cutting Height

33.2 ft in

Max Loading Height

22.7 ft in

Max Vertical Wall Digging Depth

20.2 ft in

Boom/Stick Option (HEX) 3

Boom/Stick Option (HEX) 3

Reach Boom 6150mm (20\' 2\'\') / Stick 8\' 8\'\'

Shipping Height of Unit

10.5 ft in

Shipping Length of Unit

34.2 ft in

Max Digging Depth

22.1 ft in

Max Reach Along Ground

33.4 ft in

Max Cutting Height

32.9 ft in

Max Loading Height

22.2 ft in

Max Vertical Wall Digging Depth

19.1 ft in

Boom/Stick Option (HEX) 4

Boom/Stick Option (HEX) 4

Mass Boom 5550mm (18\' 2\'\') / Stick 10\' 6\'\'

Shipping Height of Unit

10.3 ft in

Shipping Length of Unit

32.2 ft in

Max Digging Depth

22.2 ft in

Max Reach Along Ground

32.9 ft in

Max Cutting Height

31.8 ft in

Max Loading Height

21.3 ft in

Max Vertical Wall Dig Depth

18.5 ft in

Boom/Stick Option (HEX) 5

Boom/Stick Option (HEX) 5

Mass Boom 5550mm (18\' 2\'\') / Stick 8\' 2\'\'

Shipping Height of Unit

10.7 ft in

Shipping Length of Unit

32.4 ft in

Max Digging Depth

20.2 ft in

Max Reach Along Ground

31.1 ft in

Max Cutting Height

30.3 ft in

Max Loading Height

19.7 ft in

Max Vertical Wall Dig Depth

16.6 ft in

Dimensions

Width to Outside of Tracks

11.2 ft in

Height to Top of Cab

10 ft in

Ground Clearance

1.7 ft in

Removal Counterweight Clearance

3.7 ft in

Tail Swing Radius

10.2 ft in

Length of Track on Ground

13.1 ft in
