Caterpillar 323D LN Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
31.86ft in
C
Shipping Height Of Unit
10.18ft in
I
Max Cutting Height
29.34ft in
J
Max Loading Height
19.66ft in
K
Max Reach Along Ground
29.47ft in
L
Max Vertical Wall Digging Depth
12.28ft in
M
Max Digging Depth
18.97ft in
Boom/Stick Option (Hex) 1
Boom 5680mm / Stick 1900mm
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
31.04ft in
I
Max Cutting Height
30.78ft in
C
Shipping Height Of Unit
10.01ft in
J
Max Loading Height
21.63ft in
K
Max Reach Along Ground
30.98ft in
L
Max Vertical Wall Digging Depth
16.7ft in
M
Max Digging Depth
20.35ft in
Boom/Stick Option (Hex) 2
Boom 5680mm / Stick 2500mm
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
31.04ft in
I
Max Cutting Height
31.44ft in
J
Max Loading Height
22.22ft in
C
Shipping Height Of Unit
9.95ft in
K
Max Reach Along Ground
32.35ft in
L
Max Vertical Wall Digging Depth
18.12ft in
M
Max Digging Depth
21.82ft in
Boom/Stick Option (Hex) 3
Boom 5680mm / Stick 2920mm
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
30.39ft in
C
Shipping Height Of Unit
10.34ft in
I
Max Cutting Height
28.58ft in
J
Max Loading Height
18.74ft in
K
Max Reach Along Ground
27.96ft in
M
Max Digging Depth
17.49ft in
Max Vertical Wall Dig Depth
11.72ft in
Boom/Stick Option (Hex) 4
Mass Boom 5200mm / Stick 1900mm
Dimensions
E
Ground Clearance
1.51ft in
G
Height To Top Of Cab
10.01ft in
B
Width To Outside Of Tracks
8.5ft in
D
Length Of Track On Ground
11.98ft in
H
Tail Swing Radius
9.03ft in
Removal Counterweight Clearance
3.35ft in
Undercarriage
F
Track Gauge
6.53ft in
N
Shoe Size
19.69in
Ground Pressure
7.97psi
Drawbar Pull
46310.64lb
Max Travel Speed
3.42mph
Specifications
Engine
Engine Make
2236
Engine Model
3066 ATAAC
Net Power
140hp
Power Measured @
1800rpm
Displacement
390.6cu in
Aspiration
Turbocharged
Operational
Operating Weight
48193.1lb
Fuel Capacity
84.6gal
Cooling System Fluid Capacity
6.7gal
Hydraulic System Fluid Capacity
68.7gal
Operating Voltage
24V
Engine Oil Capacity
8gal
Swing Drive Fluid Capacity
2.2gal
Alternator Supplied Amperage
80amps
Hydraulic System Relief Valve Pressure
5076.4psi
Hydraulic Pump Flow Capacity
108.4gal/min
Swing Mechanism
Swing Speed
11.5rpm
Swing Torque
45728.9lb ft
Buckets
Reference Bucket Capacity
1.5yd3
