Caterpillar 312D L Hydraulic Excavator

Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Hydraulic Excavator
Units

Dimensions

Boom/Stick Option (Hex) 1

A

Shipping Length Of Unit

24.97ft in

C

Shipping Height Of Unit

9.29ft in

I

Max Cutting Height

27.83ft in

J

Max Loading Height

20.02ft in

K

Max Reach Along Ground

26.81ft in

L

Max Vertical Wall Digging Depth

16.34ft in

M

Max Digging Depth

18.18ft in

Boom/Stick Option (Hex) 1

Boom 5680mm (18\' 7\'\') / Stick 2500mm (8\\\\\\\\\\\\\\\' 2\\\\\\\\\\\\\\\'\\\\\\\\\\\\\\\')

Boom/Stick Option (Hex) 2

A

Shipping Length Of Unit

24.91ft in

I

Max Cutting Height

28.15ft in

C

Shipping Height Of Unit

9.75ft in

J

Max Loading Height

20.38ft in

K

Max Reach Along Ground

27.66ft in

L

Max Vertical Wall Digging Depth

16.93ft in

M

Max Digging Depth

19.17ft in

Boom/Stick Option (Hex) 2

Boom 5680mm (18\' 7\'\') / Stick 2800mm (9\\\\\\\' 2\\\\\\\'\\\\\\\')

Boom/Stick Option (Hex) 3

A

Shipping Length Of Unit

24.97ft in

I

Max Cutting Height

28.55ft in

J

Max Loading Height

20.81ft in

C

Shipping Height Of Unit

9.29ft in

K

Max Reach Along Ground

28.29ft in

L

Max Vertical Wall Digging Depth

17.59ft in

M

Max Digging Depth

19.82ft in

Boom/Stick Option (Hex) 3

Boom 5680mm (18\' 7\'\') / Stick 3000mm (9\\\\\\\' 10\\\\\\\'\\\\\\\')

Dimensions

E

Ground Clearance

1.42ft in

G

Height To Top Of Cab

9.06ft in

B

Width To Outside Of Tracks

8.5ft in

D

Length Of Track On Ground

9.98ft in

H

Tail Swing Radius

7.03ft in

Removal Counterweight Clearance

3.01ft in

Undercarriage

F

Track Gauge

6.53ft in

N

Shoe Size

23.63in

Max Travel Speed

3.42mph

Drawbar Pull

25628.22lb

Ground Pressure

4.87psi


Specifications

Engine

Engine Make

2236

Engine Model

C4.2 ACERT

Net Power

90hp

Gross Power

97hp

Displacement

259.4cu in

Operational

Operating Weight

29652.2lb

Fuel Capacity

66.1gal

Cooling System Fluid Capacity

4.8gal

Hydraulic System Fluid Capacity

42.8gal

Engine Oil Capacity

5.2gal

Swing Drive Fluid Capacity

0.8gal

Hydraulic System Relief Valve Pressure

5076.4psi

Hydraulic Pump Flow Capacity

33.6gal/min

Swing Mechanism

Swing Torque

22827.6lb ft

Swing Speed

12.4rpm

Buckets

Reference Bucket Capacity

0.7yd3

Minimum Bucket Capacity

0.4yd3

Maximum Bucket Capacity

1yd3
