Caterpillar 307B SB Midi Excavator

Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Units

Dimensions

Boom/Stick Option (Hex) 1

I

Max Cutting Height

20.28ft in

J

Max Loading Height

13.65ft in

K

Max Reach Along Ground

22.61ft in

L

Max Vertical Wall Digging Depth

9.85ft in

M

Max Digging Depth

13.65ft in

Boom/Stick Option (Hex) 1

boom w/ stick 1670mm

Boom/Stick Option (Hex) 2

I

Max Cutting Height

20.31ft in

J

Max Loading Height

13.69ft in

K

Max Reach Along Ground

22.58ft in

M

Max Digging Depth

13.62ft in

L

Max Vertical Wall Digging Depth

9.78ft in

Boom/Stick Option (Hex) 2

boom w/ stick 1720mm

Boom/Stick Option (Hex) 3

I

Max Cutting Height

21.3ft in

J

Max Loading Height

14.6ft in

K

Max Reach Along Ground

24.35ft in

L

Max Vertical Wall Digging Depth

11.75ft in

M

Max Digging Depth

15.42ft in

Boom/Stick Option (Hex) 3

boom w/ stick 2210mm

Dimensions

B

Width To Outside Of Tracks

7.22ft in

D

Length Of Track On Ground

6.96ft in

E

Ground Clearance

1.25ft in

G

Height To Top Of Cab

8.67ft in

H

Tail Swing Radius

5.75ft in

Removal Counterweight Clearance

2.58ft in

Undercarriage

N

Shoe Size

17.72in

F

Track Gauge

5.75ft in

Drawbar Pull

12130lb

Max Travel Speed

3.11mph


Specifications

Engine

Engine Make

2251

Engine Model

4M40E1

Gross Power

41hp

Displacement

173cu in

Bore

3.7in

Stroke

4in

Engine Model

4M40E1

Flywheel Power

40hp

Eec 80/1269

40hp

Sae J1349

40hp

Iso 9249

40hp

Operational

Operating Weight

16314.3lb

Fuel Capacity

35.7gal

Hydraulic System Fluid Capacity

27.8gal

Hydraulic Pump Flow Capacity

33.9gal/min

Weights

Operating Weight

18555lb

Hydraulic System

Pilot System - Maximum Flow

4.9 gal/min

Pilot System - Maximum Pressure

570 psi

Maximum Pressure - Travel

4550 psi

Maximum Pressure - Swing

3980 psi

Maximum Pressure - Implements

3980 psi

Main Implement System - Maximum Flow (2x)

17 gal/min

Boom Cylinder - Bore

4.3in

Boom Cylinder - Stroke

39.3in

Stick Cylinder - Bore

3.5in

Stick Cylinder - Stroke

36.7in

Blade - Maximum Flow

9 gal/min

Blade System - Maximum Pressure

2990 psi

Service Refill Capacities

Cooling System

4gal

Fuel Tank

35.7gal

Final Drive - Each

0.5gal

Hydraulic Tank

15gal

Hydraulic System - Including Tank

24.8gal

Engine Oil

1.9gal

Swing Drive - Each

0.4gal

Drive

Maximum Drawbar Pull

12360lb

Travel Speed

3.1mph
