Caterpillar 307.5 Mini Excavator
Dimensions
Dimensions - Long Stick
Ground Clearance
14.6in
Boom In Reach
88.6in
Boom Swing - Left
_-
Boom Swing - Right
_-
Tail Swing With Counterweight
78.5in
Cab Height
99in
Dig Depth
183in
Maximum Blade Depth
16.3in
Maximum Blade Height
14.3in
Maximum Dig Height
305.4in
Maximum Dump Clearance
224.8in
Maximum Reach
267.9in
Maximum Reach - Ground Level
262.7in
O/A Shipping Length
246.3in
O/A Track Width
86.6in
O/A Undercarriage Length
113.4in
Stick Length
86.9in
Swing Bearing - Height
28.7in
Tail Swing Without Counterweight
70.91in
Track Belt/Shoe Width
17.7in
Transport Height
104.6in
Vertical Wall
162.2in
Width Over Upper House
88.6in
Dimensions - Standard Stick
Ground Clearance
14.6in
O/A Shipping Length
241.9in
Tail Swing Without Counterweight
70.91in
O/A Track Width
86.6in
Width Over Upper House
88.6in
Boom Swing - Right
_-
Cab Height
99in
Vertical Wall
141.9in
Dig Depth
161.7in
O/A Undercarriage Length
113.4in
Boom Swing - Left
_-
Maximum Blade Depth
16.3in
Stick Length
65.6in
Maximum Blade Height
14.3in
Track Belt/Shoe Width
17.7in
Maximum Dig Height
289in
Swing Bearing - Height
28.7in
Maximum Dump Clearance
208.4in
Transport Height
100.7in
Tail Swing With Counterweight
78.5in
Maximum Reach
247.9in
Boom In Reach
66.2in
Maximum Reach - Ground Level
242.2in
Specifications
Swing System
Machine Swing Speed
10rpm
Engine
Net Power
55.9hp
Displacement
148cu in
Bore
3.4in
Stroke
4in
Engine Model
Cat C2.4 Turbo
Gross Power - Iso 14396
57.9hp
Rated Net Power - 2,400 Rpm - Iso 9249/Eec 80/1269
55.9hp
Weights
Operating Weight
18152 lb
Note (1)
*Minimum Weight is based on steel tracks, no counterweight, operator, full fuel tank, standard stick, blade and no bucket.
Note (2)
**Maximum Weight is based on steel tracks with rubber pads, counterweight, operator, full fuel tank, long stick, blade and no bucket.
Minimum Operating Weight With Cab*
16605lb
Maximum Operating Weight With Cab**
18152lb
Blade
Height
17in
Width
7.5ft in
Hydraulic System
Hydraulic System Type
Load Sensing Hydraulics with Variable Displacement Piston Pump
Operating Pressure - Swing
3626 psi
Operating Pressure - Equipment
4134 psi
Operating Pressure - Travel
4134 psi
Digging Force - Stick - Standard
8504lb
Digging Force - Stick - Long
7579lb
Digging Force - Bucket
12272lb
Pump Flow At 2,400 Rpm
44 gal/min
Auxiliary Circuit - Primary - Flow
35 gal/min
Auxiliary Circuit - Primary - Pressure
4134 psi
Auxiliary Circuit - Secondary - Flow
9 gal/min
Auxiliary Circuit - Secondary - Pressure
4134 psi
Service Refill Capacities
Cooling System
2.6gal
Fuel Tank
38gal
Hydraulic Tank
14gal
Hydraulic System
27gal
Engine Oil
2.5gal
Sound
Note
European Union Directive 2000/14/EC
Average Exterior Sound Pressure (Iso 6395:2008)
98 dB(A)
Operator Sound Pressure (Iso 6396:2008)
72 dB(A)
Travel System
Maximum Traction Force - High Speed
5856lb
Maximum Traction Force - Low Speed
14035lb
Travel Speed - High
3.1mph
Travel Speed - Low
1.9mph
Gradeability - Maximum
30 degrees
Ground Pressure - Minimum Weight
5 psi
Ground Pressure - Maximum Weight
5 psi
Weight Increase From Minimum Configuration
Long Stick
146lb
Counterweight
552lb
Steel Tracks With Pads
661lb
Certification - Cab
Roll Over Protective Structure (Rops)
ISO 12117-2:2008
Tip Over Protective Structure (Tops)
ISO 12117:1997
Top Guard
ISO 10262:1998 (Level II)
