Caterpillar 303.5C CR Mini Excavator

Caterpillar 303.5C CR Mini Excavator Specs front
Caterpillar 303.5C CR Mini Excavator Specs front
Caterpillar 303.5C CR Mini Excavator Specs side
Caterpillar 303.5C CR Mini Excavator Specs side
Caterpillar 303.5C CR Mini Excavator Specs extended
Caterpillar 303.5C CR Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

15.83 ft in

C

Shipping Height of Unit

8.17 ft in

I

Max Cutting Height

16.5 ft in

J

Max Loading Height

11.75 ft in

K

Max Reach Along Ground

17.18 ft in

L

Max Vertical Wall Digging Depth

8.17 ft in

M

Max Digging Depth

10.33 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

16.18 ft in

C

Shipping Height of Unit

8.17 ft in

I

Max Cutting Height

16.75 ft in

J

Max Loading Height

12 ft in

K

Max Reach Along Ground

18.08 ft in

L

Max Vertical Wall Digging Depth

8.67 ft in

M

Max Digging Depth

11.33 ft in

Dimensions

B

Width to Outside of Tracks

5.83 ft in

D

Length of Track on Ground

7.25 ft in

E

Ground Clearance

1.12 ft in

G

Height to Top of Cab

8.17 ft in

H

Tail Swing Radius

3.17 ft in

Undercarriage

F

Track Gauge

4.83 ft in

N

Shoe Size

12 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2251

Engine Model

S3Q2T

Gross Power

41 hp

Net Power

39.4 hp

Power Measured @

2400 rpm

Displacement

114.6 cu in

Operational

Operating Weight

8200 lb

Fuel Capacity

13.5 gal

Cooling System Fluid Capacity

1.6 gal

Hydraulic System Fluid Capacity

17.2 gal

Engine Oil Capacity

1.6 gal

Operating Voltage

12 V

Alternator Supplied Amperage

50 amps

Hydraulic System Relief Valve Pressure

3553 psi

Hydraulic Pump Flow Capacity

23.2 gal/min

Swing Mechanism

Swing Speed

9 rpm

Undercarriage

Shoe Size

12 in

Max Travel Speed

2.8 mph

Track Gauge

4.9 ft in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Standard Stick

Shipping Height of Unit

8.2 ft in

Shipping Length of Unit

15.9 ft in

Max Digging Depth

10.4 ft in

Max Reach Along Ground

17.2 ft in

Max Cutting Height

16.5 ft in

Max Loading Height

11.8 ft in

Max Vertical Wall Digging Depth

8.2 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Long Stick

Shipping Height of Unit

8.2 ft in

Shipping Length of Unit

16.2 ft in

Max Digging Depth

11.4 ft in

Max Reach Along Ground

18.1 ft in

Max Cutting Height

16.8 ft in

Max Loading Height

12 ft in

Max Vertical Wall Digging Depth

8.7 ft in

Dimensions

Width to Outside of Tracks

5.9 ft in

Height to Top of Cab

8.2 ft in

Ground Clearance

1.2 ft in

Removal Counterweight Clearance

1.9 ft in

Tail Swing Radius

3.2 ft in

Length of Track on Ground

7.3 ft in
