Caterpillar 256C Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
12.12ft in
B
Width Over Tires
5.5ft in
E
Ground Clearance
8.81in
C
Height To Top Of Cab
6.83ft in
D
Wheelbase
4.07ft in
F
Length W/O Bucket
10.25ft in
G
Clearance At Max Lift And Dump
7.96ft in
H
Reach At Max Lift And Dump
23.6in
Turning Radius From Center - Machine Rear
57.7in
Turning Radius From Center - Inc Bucket
95.8in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
3044C DIT
Gross Power
85hp
Net Power
82hp
Power Measured @
2500rpm
Displacement
201cu in
Operational
Operational Weight
7566lb
Fuel Capacity
26gal
Cooling System Fluid Capacity
3.7gal
Engine Oil Fluid Capacity
2.6gal
Hydraulic System Fluid Capacity
15gal
Max Speed
7.7mph
Chain Box Fluid Capacity - Each Side
2.6gal
Loader
Breakout Force
7328lb
Operating Load Rating
2350lb
Tipping Angle
4700degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
22gal/min
Relief Valve Pressure
3335psi
