Caterpillar 252B Series 2 Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

11.87ft in

B

Width Over Tires

6ft in

C

Height to Top of Cab

6.88ft in

D

Wheelbase

4.02ft in

E

Ground Clearance

7.7in

F

Length w/o Bucket

9.52ft in

G

Clearance at Max Lift and Dump

7.94ft in

H

Reach at Max Lift and Dump

32.6in


Specifications

Engine

Number of Cylinders

4

Engine Make

2236

Engine Model

3044C DIT

Gross Power

75hp

Net Power

70hp

Power Measured @

2600rpm

Displacement

201cu in

Bore

3.7in

Stroke

4.7in

Gross Power - SAE J1995

75hp

Engine Model

Cat C3.4 DIT

Net Power - SAE 1349

71hp

Net Flywheel Power

71hp

Operational

Operational Weight

7861lb

Fuel Capacity

23.8gal

Cooling System Fluid Capacity

2.6gal

Engine Oil Fluid Capacity

2.6gal

Hydraulic System Fluid Capacity

14gal

Chain Box Fluid Capacity - each side

2.1gal

Max Speed

7mph

Operating Voltage

12V

Alternator Supplied Amperage

90amps

Power Train

Travel Speed Forward

7mph

Travel Speed Reverse

7mph

Travel Speed Reverse - 2-Speed Option

11mph

Travel Speed Forward - 2-Speed Option

11mph

Weights

Operating Weight

7861lb

Loader

Breakout Force

5508

Operating Load Rating

2500lb

Tipping Angle

5501degrees

Bucket Capacity

0.5yd3

Hydraulic System

Hydraulic Power

42.8hp

Loader Hydraulic Pressure

3335 psi

Loader Hydraulic Flow

22 gal/min

Hydraulic Flow

Standard

Hydraulic

Pump Flow Capacity

22gal/min

Relief Valve Pressure

3335psi

Dimensions

Length with Bucket

11.9ft in

Length w/o Bucket

9.6ft in

Width Over Tires

6ft in

Height to Top of Cab

6.9ft in

Clearance at Max Lift and Dump

8ft in

Wheelbase

4.1ft in

Ground Clearance

7.7in

Reach at Max Lift and Dump

32.6in

Turning Radius from Center - machine rear

67in

Turning Radius from Center - inc bucket

86in

Wheel Base

4ft in

Bucket Pin Height - Maximum Lift

10.5ft in

Height - Top of Cab

6.9ft in

Length - Without Bucket

114in

Length - With Bucket on Ground

142in

Maximum Overall Height

160in

Bucket Pin Height - Carry Position

8.4in

Clearance at Maximum Lift and Dump

95in

Departure Angle

26.4 degrees

Maximum Dump Angle

51 degrees

Rack Back Angle - Maximum Height

87 degrees

Turn Radius from Center - Rear

67in

Turn Radius from Center - Coupler

52in

Turn Radius from Center - Bucket

86in

Maximum Reach - With Arms Parallel

52in

Bucket Pin Reach - Maximum Lift

13.7in

Reach - Maximum Lift/Dump

33in

Vehicle Width over Tires

72in

Bumper Overhang - Rear Axle

41in

Operating Specifications

Rated Operating Capacity with Optional Counterweight

2550lb

Tipping Load

5000lb

Breakout Force - Tilt Cylinder

5508lb

Rated Operating Capacity

2500lb

Service Refill Capacities

Cooling System

2.6gal

Fuel Tank

23.8gal

Hydraulic Tank

9.2gal

Engine Crankcase

2.4gal

Hydraulic System

14gal

Chain Box - Each Side

2.1gal

Cab

ROPS

SAE J1040 MAY94, ISO 3471:1994

FOPS

SAE J1043 SEPT87, ISO 3449:1992 Level I

FOPS Level II

SAE J231 JAN81, ISO 3449:1992 Level II
