Caterpillar 245B LC Series II Deep Trencher Hydraulic Excavator

Caterpillar 245B LC Series II Deep Trencher Hydraulic Excavator Specs front
Caterpillar 245B LC Series II Deep Trencher Hydraulic Excavator Specs front
Caterpillar 245B LC Series II Deep Trencher Hydraulic Excavator Specs side
Caterpillar 245B LC Series II Deep Trencher Hydraulic Excavator Specs side
Caterpillar 245B LC Series II Deep Trencher Hydraulic Excavator Specs extended
Caterpillar 245B LC Series II Deep Trencher Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

49.76 ft in

C

Shipping Height of Unit

15.17 ft in

I

Max Cutting Height

44.59 ft in

J

Max Loading Height

31.6 ft in

K

Max Reach Along Ground

52.27 ft in

L

Max Vertical Wall Digging Depth

26.22 ft in

M

Max Digging Depth

35.31 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

49.84 ft in

C

Shipping Height of Unit

14.76 ft in

I

Max Cutting Height

38.49 ft in

J

Max Loading Height

27.2 ft in

K

Max Reach Along Ground

51.22 ft in

L

Max Vertical Wall Digging Depth

18.97 ft in

M

Max Digging Depth

36.75 ft in

Dimensions

B

Width to Outside of Tracks

11.84 ft in

E

Ground Clearance

2.5 ft in

G

Height to Top of Cab

11.84 ft in

H

Tail Swing Radius

12.9 ft in

Undercarriage

F

Track Gauge

9.35 ft in

N

Shoe Size

36 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

3406B

Net Power

360 hp

Power Measured @

2100 rpm

Displacement

891 cu in

Aspiration

turbocharged and aftercooled

Operational

Operating Weight

162657.1 lb

Fuel Capacity

180.2 gal

Cooling System Fluid Capacity

20.5 gal

Hydraulic System Fluid Capacity

192.6 gal

Engine Oil Capacity

12.3 gal

Swing Drive Fluid Capacity

11.8 gal

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Hydraulic System Relief Valve Pressure

4500 psi

Hydraulic Pump Flow Capacity

232 gal/min

Swing Mechanism

Swing Speed

4.7 rpm

Swing Torque

141600 lb ft

Undercarriage

Number of Shoes per Side

45

Shoe Size

36 in

Ground Pressure

10.4 psi

Max Travel Speed

2 mph

Drawbar Pull

96218.3 lb

Track Gauge

9.4 ft in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 31\'3\" (9525mm) w/ Stick 14\'6\" (4420mm)

Shipping Height of Unit

15.2 ft in

Shipping Length of Unit

49.8 ft in

Max Digging Depth

35.4 ft in

Max Reach Along Ground

52.3 ft in

Max Cutting Height

44.6 ft in

Max Loading Height

31.6 ft in

Max Vertical Wall Digging Depth

26.3 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 31\'3\" (9525mm) w/ Stick 16\' (4877mm)

Shipping Height of Unit

14.8 ft in

Shipping Length of Unit

49.9 ft in

Max Digging Depth

36.8 ft in

Max Reach Along Ground

51.3 ft in

Max Cutting Height

38.5 ft in

Max Loading Height

27.2 ft in

Max Vertical Wall Digging Depth

19 ft in

Dimensions

Width to Outside of Tracks

11.9 ft in

Height to Top of Cab

11.9 ft in

Ground Clearance

2.5 ft in

Removal Counterweight Clearance

3.6 ft in

Tail Swing Radius

12.9 ft in
