Caterpillar 236B Series 3 Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

11.54 ft in

B

Width Over Tires

5.5 ft in

C

Height to Top of Cab

6.87 ft in

D

Wheelbase

3.73 ft in

E

Ground Clearance

9.31 in

F

Length w/o Bucket

9.19 ft in

G

Clearance at Max Lift and Dump

7.87 ft in

H

Reach at Max Lift and Dump

21.3 in


Specifications

Engine

Engine Make

2236

Engine Model

C3.4DIT

Gross Power

74 hp

Net Power

71 hp

Displacement

201 cu in

Bore

3.7 in

Stroke

4.7 in

Gross Power - SAE J1995

74 hp

Engine Model

Cat C3.4 DIT

Net Power - ISO 9249 EEC

71 hp

Net Power - SAE 1349

71 hp

Net Flywheel Power

71 hp

Operational

Operational Weight

7007 lb

Fuel Capacity

23.8 gal

Cooling System Fluid Capacity

2.7 gal

Engine Oil Fluid Capacity

2.4 gal

Hydraulic System Fluid Capacity

13.8 gal

Chain Box Fluid Capacity - each side

1.9 gal

Operating Speed

7.6 mph

Max Speed

11.3 mph

Operating Voltage

12 V

Alternator Supplied Amperage

90 amps

Power Train

Travel Speed Forward

7.5 mph

Travel Speed Reverse

7.5 mph

Travel Speed Reverse - 2-Speed Option

11.2 mph

Travel Speed Forward - 2-Speed Option

11.2 mph

Weights

Operating Weight

7007 lb

Loader

Breakout Force

5484

Operating Load Rating

1950 lb

Tipping Angle

3900 degrees

Hydraulic System

Hydraulic Power

42.8 hp

Loader Hydraulic Pressure

3335 psi

Loader Hydraulic Flow

22 gal/min

Hydraulic Flow

Standard

Hydraulic

Pump Flow Capacity

22 gal/min

Relief Valve Pressure

3335 psi

Dimensions

Length with Bucket

11.6 ft in

Length w/o Bucket

9.2 ft in

Width Over Tires

5.5 ft in

Height to Top of Cab

6.9 ft in

Clearance at Max Lift and Dump

7.9 ft in

Wheelbase

3.8 ft in

Ground Clearance

9.3 in

Reach at Max Lift and Dump

21.3 in

Turning Radius from Center - machine rear

63.9 in

Turning Radius from Center - inc bucket

82.4 in

Wheel Base

3.8 ft in

Bucket Pin Height - Maximum Lift

10.2 ft in

Height - Top of Cab

6.9 ft in

Length - Without Bucket

110 in

Length - With Bucket on Ground

138 in

Maximum Overall Height

156 in

Bucket Pin Height - Carry Position

8.4 in

Clearance at Maximum Lift and Dump

94 in

Departure Angle

28 degrees

Maximum Dump Angle

40 degrees

Rack Back Angle - Maximum Height

83 degrees

Turn Radius from Center - Rear

64 in

Turn Radius from Center - Coupler

52 in

Turn Radius from Center - Bucket

82 in

Maximum Reach - With Arms Parallel

53 in

Reach - Maximum Lift/Dump

21 in

Vehicle Width over Tires

66 in

Bumper Overhang - Rear Axle

41 in

Operating Specifications

Rated Operating Capacity with Optional Counterweight

2050 lb

Tipping Load

3900 lb

Breakout Force - Tilt Cylinder

5484 lb

Rated Operating Capacity

1950 lb

Service Refill Capacities

Cooling System

2.6 gal

Fuel Tank

23.8 gal

Hydraulic Tank

9.2 gal

Engine Crankcase

2.4 gal

Hydraulic System

13.7 gal

Chain Box - Each Side

1.8 gal

Cab

ROPS

SAE J1040 MAY94, ISO 3471:1994

FOPS

SAE J1043 SEPT87, ISO 3449:1992 Level I

FOPS Level II

SAE J231 JAN81, ISO 3449:1992 Level II
