Caterpillar 224 Mobile Excavator
Units
Dimensions
Boom/Stick Option (Mex) 1
I
Max Cutting Height
25.6ft in
J
Max Loading Height
18.05ft in
K
Max Reach Along Ground
28.25ft in
M
Max Digging Depth
18.02ft in
Boom/Stick Option (Mex) 1
One-Piece Boom/Stick 5'11" (1800mm)
Boom/Stick Option (Mex) 2
I
Max Cutting Height
26.09ft in
K
Max Reach Along Ground
30.19ft in
M
Max Digging Depth
19.53ft in
Boom/Stick Option (Mex) 2
One-Piece Boom/Stick 7'6.5" (2300mm)
Boom/Stick Option (Mex) 3
I
Max Cutting Height
25.27ft in
K
Max Reach Along Ground
31.76ft in
M
Max Digging Depth
21.33ft in
Boom/Stick Option (Mex) 3
One-Piece Boom/Stick 9'2" (2800mm)
Boom/Stick Option (Mex) 4
I
Max Cutting Height
30.19ft in
J
Max Loading Height
22.15ft in
K
Max Reach Along Ground
29.7ft in
M
Max Digging Depth
16.41ft in
Boom/Stick Option (Mex) 4
Two-Piece Boom/Stick 5'11" (1800mm)
Dimensions
D
Wheelbase
8.7ft in
B
Overall Width
8.17in
E
Ground Clearance
1.15ft in
F
Overall Width - Outriggers Down
11.98ft in
G
Height To Top Of Cab
10.55ft in
N
Upper Structure Clearance
4.19ft in
Specifications
Engine
Engine Make
2349
Engine Model
BF6L 913
Gross Power
143.5hp
Displacement
374.1cu in
Operational
Fuel Capacity
60.8gal
Hydraulic System Fluid Capacity
92.5gal
Hydraulic System Relief Valve Pressure
4351.2psi
Hydraulic Pump Flow Capacity
85.6gal/min
Tire Size
dual 10.00-20
