Caterpillar 216B Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

10.61ft in

B

Width Over Tires

5.01ft in

C

Height to Top of Cab

6.4ft in

D

Wheelbase

3.24ft in

E

Ground Clearance

8in

F

Length w/o Bucket

8.27ft in

G

Clearance at Max Lift and Dump

7.12ft in

H

Reach at Max Lift and Dump

19.89in


Specifications

Engine

Engine Make

2236

Engine Model

3024C

Gross Power

52hp

Net Power

49.7hp

Bore

3.3in

Stroke

3.9in

Gross Power - SAE J1995

52hp

Engine Model

Cat 3024C

Engine Power - ISO 14396

51hp

Net Power - EEC 80/1269

50hp

Net Power - ISO 9249 EEC

50hp

Net Power - SAE 1349

49hp

Net Flywheel Power

49hp

Operational

Operational Weight

5707.8lb

Fuel Capacity

17.2gal

Cooling System Fluid Capacity

2.7gal

Engine Oil Fluid Capacity

2.2gal

Hydraulic System Fluid Capacity

14.6gal

Chain Box Fluid Capacity - each side

1.6gal

Max Speed

7.8mph

Tire Size

10x16.5 6PR

Operating Voltage

12V

Alternator Supplied Amperage

65amps

Power Train

Travel Speed Forward

7.9mph

Travel Speed Reverse

7.9mph

Weights

Operating Weight

5709lb

Loader

Breakout Force

3785.4

Operating Load Rating

1400lb

Tipping Angle

2799.9degrees

Hydraulic System

Hydraulic Power

28.2hp

Loader Hydraulic Pressure

3100 psi

Loader Hydraulic Flow

15.6 gal/min

Hydraulic Flow

Standard flow

Hydraulic

Pump Flow Capacity

15.9gal/min

Relief Valve Pressure

3103.9psi

Dimensions

Length with Bucket

10.7ft in

Length w/o Bucket

8.3ft in

Width Over Tires

5.1ft in

Height to Top of Cab

6.4ft in

Clearance at Max Lift and Dump

7.2ft in

Wheelbase

3.3ft in

Ground Clearance

8in

Reach at Max Lift and Dump

19.9in

Turning Radius from Center - machine rear

58.5in

Turning Radius from Center - inc bucket

76.4in

Wheel Base

3.3ft in

Bucket Pin Height - Maximum Lift

9.4ft in

Height - Top of Cab

6.5ft in

Length - Without Bucket

99in

Length - With Bucket on Ground

127in

Maximum Overall Height

146in

Bucket Pin Height - Carry Position

9.3in

Clearance at Maximum Lift and Dump

85in

Turn Radius from Center - Rear

58.5in

Turn Radius from Center - Coupler

47.2in

Turn Radius from Center - Bucket

76.4in

Maximum Reach - With Arms Parallel

50.4in

Reach - Maximum Lift/Dump

20in

Vehicle Width over Tires

60in

Bumper Overhang - Rear Axle

38in

Operating Specifications

Rated Operating Capacity with Optional Counterweight

1500lb

Tipping Load

2800lb

Breakout Force - Tilt Cylinder

3787lb

Breakout Force - Lift Cylinder

3057lb

Rated Operating Capacity

1400lb

Service Refill Capacities

Cooling System

2.6gal

Fuel Tank

17gal

Hydraulic Tank

9.2gal

Engine Crankcase

2.1gal

Hydraulic System

14.5gal

Chain Box - Each Side

1.6gal

Cab

ROPS

SAE J1040 MAY94 and ISO3471:1994

FOPS

SAEJ/ISO 3449 APR98 Level I and ISO3449:1992 Level I

FOPS Level II

SAEJ/ISO 3449 APR 98 Level II and ISO 3449:1992 Level II (optional)
