Caterpillar 205 Hydraulic Excavator

Caterpillar 205 Hydraulic Excavator Specs front
Caterpillar 205 Hydraulic Excavator Specs front
Caterpillar 205 Hydraulic Excavator Specs side
Caterpillar 205 Hydraulic Excavator Specs side
Caterpillar 205 Hydraulic Excavator Specs extended
Caterpillar 205 Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

23.89 ft in

C

Shipping Height of Unit

9.96 ft in

I

Max Cutting Height

20.67 ft in

J

Max Loading Height

14.41 ft in

K

Max Reach Along Ground

23.59 ft in

M

Max Digging Depth

14.57 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

23.96 ft in

C

Shipping Height of Unit

9.96 ft in

I

Max Cutting Height

21.1 ft in

J

Max Loading Height

15.1 ft in

K

Max Reach Along Ground

25.76 ft in

M

Max Digging Depth

16.08 ft in

Boom/Stick Option (HEX) 3

A

Shipping Length of Unit

23.96 ft in

C

Shipping Height of Unit

9.96 ft in

I

Max Cutting Height

20.58 ft in

J

Max Loading Height

14.67 ft in

K

Max Reach Along Ground

26.84 ft in

M

Max Digging Depth

17.82 ft in

Boom/Stick Option (HEX) 4

A

Shipping Length of Unit

- -

C

Shipping Height of Unit

9.96 ft in

I

Max Cutting Height

24.35 ft in

J

Max Loading Height

18.64 ft in

K

Max Reach Along Ground

24.81 ft in

M

Max Digging Depth

13.75 ft in

Boom/Stick Option (HEX) 5

C

Shipping Height of Unit

9.96 ft in

I

Max Cutting Height

25.23 ft in

K

Max Reach Along Ground

26.42 ft in

M

Max Digging Depth

15.42 ft in

Boom/Stick Option (HEX) 6

C

Shipping Height of Unit

9.96 ft in

I

Max Cutting Height

25.07 ft in

K

Max Reach Along Ground

27.83 ft in

M

Max Digging Depth

17 ft in

Dimensions

B

Width to Outside of Tracks

7.86 ft in

D

Length of Track on Ground

9.9 ft in

E

Ground Clearance

1.47 ft in

G

Height to Top of Cab

9.96 ft in

H

Tail Swing Radius

6.24 ft in

Undercarriage

F

Track Gauge

6.22 ft in

N

Shoe Size

19.69 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2351

Engine Model

4.236

Net Power

71 hp

Power Measured @

2150 rpm

Displacement

235.6 cu in

Operational

Operating Weight

28957.8 lb

Fuel Capacity

48.9 gal

Cooling System Fluid Capacity

8 gal

Hydraulic System Fluid Capacity

63.5 gal

Engine Oil Capacity

2.3 gal

Swing Drive Fluid Capacity

2.6 gal

Operating Voltage

24 V

Hydraulic System Relief Valve Pressure

4351.2 psi

Hydraulic Pump Flow Capacity

49.2 gal/min

Swing Mechanism

Swing Speed

11.3 rpm

Undercarriage

Number of Shoes per Side

47

Shoe Size

19.7 in

Ground Pressure

5.7 psi

Max Travel Speed

2.5 mph

Drawbar Pull

15354.5 lb

Track Gauge

6.3 ft in

Buckets

Reference Bucket Capacity

0.7 yd3

Minimum Bucket Capacity

0.4 yd3

Maximum Bucket Capacity

1 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

One-Piece Boom, Stick 5'3" (1600mm)

Shipping Height of Unit

10 ft in

Shipping Length of Unit

23.9 ft in

Max Digging Depth

14.6 ft in

Max Reach Along Ground

23.6 ft in

Max Cutting Height

20.7 ft in

Max Loading Height

14.5 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

One-Piece Boom, Stick 6'10.5" (2100mm)

Shipping Height of Unit

10 ft in

Shipping Length of Unit

24 ft in

Max Digging Depth

16.1 ft in

Max Reach Along Ground

25.8 ft in

Max Cutting Height

21.1 ft in

Max Loading Height

15.1 ft in

Boom/Stick Option (HEX) 3

Boom/Stick Option (HEX) 3

One-Piece Boom, Stick 8'6" (2600mm)

Shipping Height of Unit

10 ft in

Shipping Length of Unit

24 ft in

Max Digging Depth

17.9 ft in

Max Reach Along Ground

26.9 ft in

Max Cutting Height

20.6 ft in

Max Loading Height

14.7 ft in

Boom/Stick Option (HEX) 4

Boom/Stick Option (HEX) 4

Two-Piece Boom, Stick 5'3" (1600mm)

Shipping Height of Unit

10 ft in

Max Digging Depth

13.8 ft in

Max Reach Along Ground

24.9 ft in

Max Cutting Height

24.4 ft in

Max Loading Height

18.7 ft in

Boom/Stick Option (HEX) 5

Boom/Stick Option (HEX) 5

Two-Piece Boom, Stick 6'10.5" (2100mm)

Shipping Height of Unit

10 ft in

Max Digging Depth

15.5 ft in

Max Reach Along Ground

26.5 ft in

Max Cutting Height

25.3 ft in

Boom/Stick Option (HEX) 6

Boom/Stick Option (HEX) 6

Two-Piece Boom, Stick 8'6" (2600mm)

Shipping Height of Unit

10 ft in

Max Digging Depth

17 ft in

Max Reach Along Ground

27.9 ft in

Max Cutting Height

25.1 ft in

Dimensions

Width to Outside of Tracks

7.9 ft in

Height to Top of Cab

10 ft in

Ground Clearance

1.5 ft in

Removal Counterweight Clearance

3.7 ft in

Tail Swing Radius

6.3 ft in

Length of Track on Ground

9.9 ft in
