Caterpillar 12H ES Motor Grader

Caterpillar 12H ES Motor Grader Specs front
Caterpillar 12H ES Motor Grader Specs front
Caterpillar 12H ES Motor Grader Specs side
Caterpillar 12H ES Motor Grader Specs side
Caterpillar 12H ES Motor Grader Specs back
Caterpillar 12H ES Motor Grader Specs back
Units

Dimensions

Dimensions

A

Overall Length

28.12 ft in

B

Width Over Tires

8.01 ft in

D

Wheelbase

19.99 ft in

H

Blade Base

8.44 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3306 DIT

Max Power

140 hp

Net Power Gears 7-8

140 hp

Displacement

637.7 cu in

Operational

Std Operation Weight - Total

31411.5 lb

Fuel Capacity

75.1 gal

Hydraulic System Fluid Capacity

18 gal

Tire Size

12-24 10PR (G-2)

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Steering

Articulation Angle

20 degrees

Turning Radius

24.3 ft in

Transmission

Number of Gears - Forward

8

Number of Gears - Reverse

6

Max Speed - Forward

24.7 mph

Max Speed - Reverse

19.5 mph

Front Axle

Wheel Lean

18 degrees

Oscillation - Total

32 degrees

Moldboard

Moldboard Width

12.1 ft in

Moldboard Height

24.1 in

Moldboard Thickness

0.9 in

Hydraulic System

Pump Type

Axial Piston

Pump Flow

54.5 gal/min

Relief Valve Pressure

3500 psi

Circle

Max Lift Above Ground

18 in

Dimensions

Height to Top of Isomount Cab

10.3 ft in

Overall Length

28.2 ft in

Width Over Tires

8.1 ft in

Wheelbase

20 ft in

Blade Base

8.5 ft in
