Case TX742 Telescopic Forklift

Case TX742 Telescopic Forklift Specs front
Case TX742 Telescopic Forklift Specs front
Case TX742 Telescopic Forklift Specs side
Case TX742 Telescopic Forklift Specs side
Case TX742 Telescopic Forklift Specs extended
Case TX742 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

20.08 ft in

B

Width Over Tires

8 ft in

C

Overall Height

8.33 ft in

D

Wheelbase

10.18 ft in

E

Ground Clearance

1.86 ft in

Lift

F

Max Lift Height

42 ft in

G

Max Forward Reach

28.88 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

Family IV 4.5 L

Gross Power

101 hp

Net Power

95 hp

Power Measured @

2200 rpm

Max Torque

295 lb ft

Displacement

276 cu in

Aspiration

turbocharged

Operational

Operating Weight

22700 lb

Fuel Capacity

36 gal

Hydraulic System Fluid Capacity

49 gal

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Tire Size

13.00 x 24 14PR

Transmission

Transmission Type

Powershift

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - forward

21.5 mph

Max Speed - reverse

21.5 mph

Hydraulic

Pump Type

Gear

Pump Flow Capacity

30 gal/min

Lift

Max Lift Capacity

6600 lb

Max Lift Height

42 ft in

Max Load at Max Height

3500 lb

Max Forward Reach

28.9 ft in

Max Load at Max Reach

1300 lb

Dimensions

Length to Fork Face

20.1 ft in

Width Over Tires

8 ft in

Overall Height

8.4 ft in

Wheelbase

10.2 ft in

Ground Clearance

1.9 ft in

Turning Radius Outside Tires

12.5 ft in
