Case TC1055 Telescopic Forklift
Units
Dimensions
Dimensions
E
Ground Clearance
20ft in
C
Overall Height
8.33ft in
D
Wheelbase
4.34ft in
Turning Radius Outside Tires
153ft in
Lift
F
Max Lift Height
5.48ft in
G
Max Forward Reach
40.42ft in
Max Lift Capacity
10000lb
Specifications
Engine
Engine Make
2239
Engine Model
Family IV 4.5 L
Gross Power
120hp
Net Power
108hp
Max Torque
380lb ft
Displacement
276cu in
Aspiration
4-Cylinder, turbocharged
Operational
Operating Weight
30754lb
Fuel Capacity
36gal
Hydraulic System Fluid Capacity
51.7gal
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Tire Size
14.00 x 24 16PR
Transmission
Transmission Type
Powershift
Number Of Forward Gears
4
Max Speed - Forward
21.5mph
Hydraulic
Pump Type
Gear
Pump Flow Capacity
32gal/min
