Case SV208D Vibratory Smooth Drum Roller

Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Units

Dimensions

Dimensions

A

Overall Length

207.49in

B

Overall Width

6.16ft in

D

Wheelbase

105.91in

E

Ground Clearance

15.2in


Specifications

Electrical System

Voltage

24 V

Battery

2 X 61 Amp

Alternator

45amps

Engine

Emissions Certification

Tier 4 Final

Gross engine horsepower

2200

Number of Cylinders

4

Engine Make

Deutz

Engine Model

TCD3.6 L4

Gross Power

74.3hp

Max Torque

287.7lb ft

Displacement

221cu in

Drive Train

Emergency brake

Multi-disc

Parking brakes

Multi-disc

piston type wheel drive pump

1

Wheel drive

2

Grade ability without traction assist

43degrees

With ATC Automatic Traction Control

48degrees

Differential / Lock system

Drive motor interlock

With HX Drive Traction Assist

65degrees

Drive

Hydrostatic

Travel speed

4-Front/Revers

Transport speed, maximum

8.7-mph,14(Kph)

Capacities

Vibration system

408.9cu in

Hydraulic oil tank

19.1gal

Fuel Tank

67.4gal

Transmission

0.7gal

Engine Oil

2.7gal

Engine coolant

7.4gal

Operational

Smooth drum Operating weight with Cab

15167.9lb

Smooth drum Max. weight with Cab

20635.3lb

Smooth drum Drum weight

8796.5lb

Smooth drum_Static linear load

52.3lb

Pad foot drum_Operating weight with out cab

17570.9lb

Padfoot drum_ Max. weight with cab

23038.4lb

Drum

Smooth drum

4.3ft in

Padfoot drum

55in

Frame extensions

3.9in

Drum thickness

1in

Drum Width

66in

Dimensions

Overall height

9.5ft in

Wheelbase

106in

Turning Radius - Inside

10.5ft in

Turning Radius - Outside

16.9ft in

Overall Length

207.5in

Overall Width

6.2ft in

Ground Clearance

15.2in
