Case IH WD 1504 Swather
Units
Dimensions
Dimensions
A
Length W/ Header
23.38ft in
C
Height To Top Of Cab
11.2ft in
D
Wheelbase
140.52in
F
Length W/O Header
16.86ft in
Track Width
148.5 in (3771 mm) Drive
Crop Clearance
42.52in
Track Width (Engine End)
90, 105 or 120 in(2286, 2667 or 3048 mm)
Weight, W/O Header
11,680 to 12,470 (5299 to 5658) Ib(Kg)
Specifications
Speeds
Maximum Road Speed
19mph
Engine
Emission Tier Level
Tier 3
Radiator Core Type
Rotary Wand and duct
Fuel Tank
120gal
Number Of Cylinders
4
Max. Horsepower
161hp
Def Tank Capacity
19gal
Engine Make
Case IH FPT
Power
150hp
Displacement
274.7cu in
Aspiration
Turbo, with air-to-air inter cooler
Alternator
150amps
Transmission
Transmission Type
Hydrostatic, 2-speed Standard
Tires
Tire Size Engine
14Lx16.1 8PR or 16.5Lx16.1 8 PR
Cab Suspension
Standard
Drive Tires
480/80 R26 R3
