Case IH PUMA 240 (2018-Present) 4WD Tractor
Units
Dimensions
Dimensions
Overall Width
112.01in
Wheelbase 4wd
113.59in
Specifications
Drawbar
Description
Category 3, Swinging
Electrical System
System
12V
Engine
Fuel Injection
Direct
Fan Drive Method
BorgWarner Visctronic std, Reversible opt.
Emissions Level
Tier 4B / Final
Number Of Cylinders
6
Def Tank Capacity
12.7gal
Advertised Rated Engine Power
240hp
Maximum Engine Power
270hp
Power Boost
30hp
Pto Horsepower
210hp
Pto Operational Type
Independent
Block Design
Parent bore
Engine Make
Case IH FPT
Engine Model
Puma 240 (2018-Present)
Rated Engine Speed
2100rpm
Fuel Tank Capacity
103gal
Displacement
408.9cu in
Bore
4.1in
Stroke
5.2in
Aspiration
Turbocharged, air-to-air aftercooled
Fuel System
High Pressure Common Rail
Transmission
Manufacturers Description
CVXDrive
Transmission Type
Continuously Variable (CVT)
Maximum Speed Forward
24.9mph
Weights
Weight Without Ballast
16799.3lb
Weight With Maximum Ballast
28660.1lb
Tires
Front
380/85 (14.9) R34
Rear
480/80 (18.4) R46
Hydraulic System
Optional Pump Flow
45gal/min
Hydraulic System Type
Closed Center, Pressure Flow Compensated (PFC)
Axles
Axle Output End
Bar
Hydraulic System
Implement Pump Flow
39.7gal/min
Pump Type
Variable Displacement
Axles
Final Drive
Planetary or Inboard
Axle Diameter
4.2in
Hydraulic System
Number Of Remote Control Valves
3 standard 4th and 5th optional
3-Point Hitch
Optional Lift Capacity @ 24”
14499.9lb
Category
Category 2 or 3
Lift Capacity @ 24”
9449.1lb
Draft Sensing
Electronic Draft Control (EDC)
Brakes
Service Brake
Wet disc
