Case IH PUMA 160 POWERSHIFT (2011-2013) 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
MODEL.UNITS

Dimensions

Dimensions

C

Height To Top Of Cab

118.31in

D

Wheelbase

107.8 (2739) / 109.7 (2786) Suspended Axle

Length, Mfd/4wd Or Track, Incl. Hitch/Drawba

179.49in


Specifications

Drawbar

Description

Swinging

Electrical System

System

12V

Engine

Fuel Injection

Direct

Fan Drive Method

BorgWarner Visctronic

Emissions Level

Tier 4A (Interim)

Number Of Cylinders

6

Def Tank Capacity

12.7gal

Advertised Rated Engine Power

160hp

Maximum Engine Power

203hp

Power Boost

43hp

Pto Horsepower

135hp

Pto Operational Type

Independent

Block Design

Parent bore

Engine Make

Case IH FPT

Engine Model

Puma 160 Powershift (2011-2013)

Rated Engine Speed

2200rpm

Fuel Tank Capacity

87gal

Displacement

408.9cu in

Bore

4.1in

Stroke

5.2in

Aspiration

Turbocharged, air-to-air aftercooled

Fuel System

High Pressure Common Rail

Transmission

Manufacturers Description

18 x 6 Full Powershift

Transmission Type

Full powershift

Maximum Speed Forward

24.9mph

Number Of Forward Gears

18

Number Of Reverse Gears

6

Weights

Weight Without Ballast

13900.2lb

Weight With Maximum Ballast

23148.6lb

Tires

Front

14.9 R30, R1W

Rear

18.4 R42, R1W

Hydraulic System

Hydraulic System Type

Closed Center, Pressure Flow Compensated (PFC)

Axles

Axle Output End

Flange or bar

Hydraulic System

Implement Pump Flow

26.5gal/min

Pump Type

Variable Displacement

Axles

Final Drive

Planetary or Inboard

Axle Diameter

3.7in

Hydraulic System

Number Of Remote Control Valves

2 standard 3 and 4 optional

3-Point Hitch

Optional Lift Capacity @ 24”

9199.9lb

Category

Category 2

Lift Capacity @ 24”

7901.4lb

Draft Sensing

Electronic Draft Control (EDC)

Brakes

Service Brake

Wet disc
