Case IH PRECISION DISK 500, 5-SECTION Air Drill
Units
Dimensions
Dimensions
Basic Weight, Maximum
44905.96lb
Basic Weight, Minimum
36598.94lb
Number Of Furrows, Maximum
96
Number Of Furrows, Minimum
60
Transport Height- Maximum
14.83ft in
Transport Height- Minimum
13.19ft in
Transport Width- Maximum
18.71ft in
Transport Width-Minimum
18.71ft in
Variants Available
2 widths, 2 row spacings
Working Width- Maximum,
60.01ft in
Working Width- Minimum
50ft in
Specifications
Configuration
Seeding Method
No-Till disk, parallel link
Primary Opener Assembly
Opener Type
Single 18 (457) coulter, 7 degree angle
Tires And Frame
Center Frame Tire
16.5x16.1 dual front and rear
Primary Opener Assembly
Depth Gauging System
4.5 (114) wide gauge wheel
Configuration
Row Spacings
10 (254) in (mm) standard or 7.5 (191) in (mm) optional
Seed Supply
Air Cart
Tires And Frame
Wing Frame Tire
12.5Lx15 single front and rear inner single outer
Primary Opener Assembly
Seeding Depth, Maximum
3.6in
Configuration
Frame Sections
5 section
Primary Opener Assembly
Down Pressure, Minimum
161lb
Down Pressure, Maximum
399.1lb
Tires And Frame
Number Of Ranks
2
Configuration
Transport Folding Method
double fold vertical
Tires And Frame
Distance Between Ranks
59.1in
Engine
Engine Make
Case IH
Engine Model
Precision Disk 500, 5-Section
Wheels
Press Wheels Mounted On Opener Or To Frame
Mounted on opener
Press Wheel Description
4 (102) wide double edged
