Case IH MAXXUM 115 MULTICONTROLLER (2012-2014) 4WD Tractor
Units
Dimensions
Dimensions
C
Height To Top Of Cab
114.18in
D
Wheelbase
105 -in (2679)- mm - Suspended
Length, Mfd/4wd Or Track, Incl. Hitch/Drawba
176.42in
Length, Mfd/4wd Or Track, Incl. Hitch/Drawbar Suspended
178.43in
Overall Width
98in
Wheelbase 4wd
103.43in
Specifications
Drawbar
Description
Category 3, Swinging
Electrical System
System
12V
Engine
Fuel Injection
Direct
Fan Drive Method
Viscous
Emissions Level
Tier 4A (Interim)
Number Of Cylinders
6
Def Tank Capacity
9.8gal
Advertised Rated Engine Power
116hp
Maximum Engine Power
154hp
Power Boost
38hp
Pto Horsepower
95hp
Pto Operational Type
Independent
Block Design
Parent bore
Engine Make
Case IH
Engine Model
Maxxum 115 MultiController (2012-2014)
Rated Engine Speed
2200rpm
Fuel Tank Capacity
60gal
Displacement
408.9cu in
Bore
4.1in
Stroke
5.2in
Aspiration
Turbocharged with air-to-air intercooler
Alternator
120amps
Fuel System
High Pressure Common Rail
Transmission
Manufacturers Description
16x16 Semi-Powershift
Transmission Type
Semi-Powershift
Maximum Speed Forward
25mph
Number Of Forward Gears
16
Number Of Reverse Gears
16
Weights
Weight Without Ballast
12500.3lb
Weight With Maximum Ballast
19841.7lb
Tires
Front
380/85 (14.9) R28 R1W
Rear
460/85 (18.4) R38 R1W
Hydraulic System
Optional Pump Flow
Hydraulic System Type
Pressure Flow Compensating (PFC)
Implement Pump Flow
26.4gal/min
Pump Type
Variable Displacement
Axles
Final Drive
Planetary or Inboard
Axle Diameter
3.7in
Hydraulic System
Number Of Remote Control Valves
3 standard, 4 optional
3-Point Hitch
Category
Category 2
Lift Capacity @ 24”
6900.5lb
Draft Sensing
Electronic, lower link pins
Brakes
Service Brake
Wet disc
