Case IH Maxxum 115 MFWD Tractor

MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MODEL.UNITS

Dimensions

Dimensions

D

Wheelbase

8.74ft in

Height With Rops

9.51ft in


Specifications

Engine

Number Of Cylinders

6

Gross Power

115hp

Pto Power

95hp

Power Measured @

2200rpm

Displacement

412cu in

Aspiration

Turbocharged, aftercooled

Operational

Operating Weight

10714lb

Fuel Capacity

66.1gal

3 Point Hitch Lift Capacity @ 24 Inches

7509lb

Rear Tires Size 2wd/4wd

18.4R34

Alternator Supplied Amperage

120amps

Transmission

Transmission Type

Synchro

Number Of Forward Gears

12

Number Of Reverse Gears

12

Hydraulic System

Pump Flow Capacity

27.1gal/min

Number Of Remote Control Valves

2


MODEL.COMPARESIMILARM

MODEL.MANUFACTURERMOD

3 Point Hitch Lift Capacity @ 24 Inches

Gross Power

Operating Weight

3 Point Hitch Lift Capacity @ 24 Inches

7509 lb

Gross Power

125 hp

Operating Weight

10714 lb

3 Point Hitch Lift Capacity @ 24 Inches

7509 lb

Gross Power

110 hp

Operating Weight

10449 lb

3 Point Hitch Lift Capacity @ 24 Inches

8084.4 lb

Gross Power

117 hp

Operating Weight

10031.1 lb
