Case IH MAXXUM 110 PRO (2007-2011) 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
Units

Dimensions

Dimensions

C

Height to Top of Cab

114.18in

D

Wheelbase

7.92ft in


Specifications

Drawbar

Description

Swinging

Electrical System

System

12V

Alternator

120amps

Engine

Fuel injection

Direct

Fan drive method

Viscous

Emissions level

Tier 3

Number of Cylinders

4

Rated engine speed

2200rpm

Advertised Rated Engine Power

110hp

Maximum Engine Power

130hp

Power Boost

20hp

PTO Horsepower

90hp

PTO Speed

PTO operational Type

Independent

Block Design

Parent bore

Engine Make

Case IH FPT

Engine Model

Maxxum 110 Pro (2007-2011)

Fuel tank capacity

46.5gal

Displacement

274.7cu in

Bore

4.1in

Stroke

5.2in

Aspiration

Turbocharged with air-to-air intercooler

Fuel system

High Pressure Common Rail

Transmission

Manufacturers Description

16F / 16R Semi Powershift

Transmission Type

Semi Powershift

Maximum Speed Forward

24.9mph

Number of Forward Gears

16

Number of Reverse Gears

16

Weights

Weight without ballast

10450lb

Weight 2WD with Cab

10081.8lb

Tires

Front

14.9 R28 R1W

Rear

18.4 R38 R1W

Hydraulic System

Hydraulic System Type

Pressure Flow Compensated

Implement Pump Flow

26.5gal/min

Optional Pump Flow

58.2

Pump Type

Variable Displacement

Number of Remote Control Valves

2

Axles

Final Drive

Planetary or Inboard

Axle Diameter

3.7in

3-Point Hitch

Category

Category 2 or 3N

Lift capacity @ 24”

9621lb

Draft sensing

Mechanical or Electronic

Brakes

Service brake

Wet disc

Dimensions

Length, MFD/4WD or track, incl. Hitch/Drawbar suspended

164.7in

Height to top of cab

114.2in

Wheelbase

8ft in

Wheelbase 2WD

93.4in

Height to Top of Suspended Cab

9.5ft in

Height to Top of Isomount Cab

9.3ft in

`
