Case IH MAGNUM 380 WHEELED CVT 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
Units

Dimensions

Dimensions

C

Height to Top of Cab

131.46in

D

Wheelbase

10.34ft in


Specifications

Drawbar

Description

Category 4, adjustable

Electrical System

System

12V

Alternator

200amps

Engine

Fuel injection

Direct

Emissions level

Final Tier 4B

Number of Cylinders

6

Rated engine speed

2000rpm

DEF tank capacity

23gal

Advertised Rated Engine Power

379.6hp

Maximum Engine Power

434.5hp

Power Boost

55hp

PTO Horsepower

315.2hp

PTO Speed

PTO operational Type

Independent

Block Design

Wet liners

Fuel System Control

Electronic

Steering Configuration

Front Steer

Drive Wheels / Tracks

4WD

Engine Make

Case IH FPT

Engine Model

Magnum 380 Wheeled CVT

Fuel tank capacity

168.1gal

Displacement

531cu in

Bore

4.7in

Stroke

5.4in

Aspiration

eVGT Turbocharged, Aftercooled

Fan drive type

BorgWarner Visctronic

Fuel system

High Pressure Common Rail

Transmission

Manufacturers Description

CVT w/Economy, 25 mph/40 kph

Transmission Type

Continuously variable

Maximum Speed Forward

24.9mph

Number of Forward Gears

4

Number of Reverse Gears

2

Weights

Weight without ballast

31191lb

Weight with maximum ballast

39198.2lb

Tires

Front

420/85, R34, R1W

Rear

480/80 R50, R1W Duals

Hydraulic System

Hydraulic System Type

Pressure Flow Compensated

Main pump type

Variable Displacement

Implement Pump Flow

43.9gal/min

Number of Remote Control Valves

4 - standard, 5 or 6 - optional

Axles

Axle Output End

Bar

Final Drive

Inboard / Planetary

Axle Diameter

5in

3-Point Hitch

Category

Category 3 / 4N HD

Lift capacity @ 24”

19899lb

Draft sensing

Electronic, lower link

Brakes

Service brake

Wet disc

Dimensions

Height to top of cab

131.5in

Wheelbase

10.4ft in

Overall Width

120in

`
