Case IH MAGNUM 260 WHEELED PS OR CVT 4WD Tractor
Units
Dimensions
Dimensions
C
Height To Top Of Cab
131.46in
D
Wheelbase
10.03ft in
Length
247.05in
Overall Width
120in
Specifications
Drawbar
Description
Category 3 standard, Category 4 optional
Electrical System
System
12V
Alternator
200amps
Engine
Fuel Injection
Direct
Emissions Level
Tier 4A (Interim)
Number Of Cylinders
6
Def Tank Capacity
23.6gal
Advertised Rated Engine Power
253.5hp
Maximum Engine Power
293.7hp
Power Boost
40.3hp
Pto Horsepower
214.6hp
Pto Operational Type
Independent
Block Design
Wet liners
Fuel System Control
Electronic
Steering Configuration
Front Steer
Drive Wheels / Tracks
4WD
Engine Make
Case IH FPT
Engine Model
Magnum 260 Wheeled PS or CVT
Rated Engine Speed
2000rpm
Fuel Tank Capacity
168.1gal
Displacement
408.9cu in
Bore
4.7in
Stroke
5.4in
Aspiration
Turbocharged, charge air cooled
Fan Drive Type
BorgWarner Visctronic
Fuel System
High Pressure Common Rail
Transmission
Manufacturers Description
19F Speed Power Shift-Economy, 25 mph/40 kph
Transmission Type
Full Powershift
Maximum Speed Forward
24.9mph
Number Of Forward Gears
19
Number Of Reverse Gears
4
Weights
Weight Without Ballast
27161lb
Weight With Maximum Ballast
29542lb
Tires
Front
380/85 R34, R1
Rear
480/80 R46, R1 Duals
Hydraulic System
Hydraulic System Type
Pressure Flow Compensated
Main Pump Type
Variable Displacement
Axles
Axle Output End
Bar
Hydraulic System
Implement Pump Flow
43.9gal/min
Axles
Final Drive
Inboard / Planetary
Axle Diameter
4.1in
Hydraulic System
Number Of Remote Control Valves
4 - standard, 5 or 6 - optional
3-Point Hitch
Category
Category 3 / 3N
Lift Capacity @ 24”
12070.4lb
Draft Sensing
Electronic, lower link
Brakes
Service Brake
Wet disc
