Case IH LBX332 Standard Baler
Units
Dimensions
Baler Pickup
Lift Type
hydraulic
Number Of Bars
4
Number Of Tines
56
Tine To Tine Width
5.75ft in
Dimensions
A
Overall Length
27.75ft in
B
Overall Width
8.42ft in
C
Overall Height
10ft in
Tractor Pto Power Required
102hp
Weight
15983lb
Specifications
Bale Size
Bale Length - Min
3.8ft in
Bale Height
2.8ft in
Bale Width
2.6ft in
Bale Length - Max
9ft in
Feeding Chamber
Packer Type
2 forks, 4 single tines
Stuffer Type
4-tine
Plunger
Spm
42
Stroke Length
28in
Density Control
hydraulic
Bearing Type
4 vertical, 2 horizontal roller
Wrapping System
Twine Type
4 double knotter
Twine Ball Capacity
30
