Case IH JX60 Utility Tractor

Case IH JX60 Utility Tractor Specs front
Case IH JX60 Utility Tractor Specs front
Case IH JX60 Utility Tractor Specs side
Case IH JX60 Utility Tractor Specs side
Case IH JX60 Utility Tractor Specs back
Case IH JX60 Utility Tractor Specs back
Units

Dimensions

Dimensions

D

Wheelbase

7.17 ft in


Specifications

Engine

Number of Cylinders

3

Gross Power

55 hp

PTO Power

45 hp

Power Measured @

2500 rpm

Displacement

177

Aspiration

Naturally Aspirated

Operational

Operating Weight

5813 lb

Fuel Capacity

23.8 gal

3 Point Hitch Lift Capacity @ 24 inches

4010 lb

Rear Tires Size 2wd/4wd

14.9 x 28

Alternator Supplied Amperage

85 amps

Transmission

Transmission Type

12x12 w / mechanical shuttle

Number of Forward Gears

12

Number of Reverse Gears

12

Hydraulic System

Relief Valve Setting

2755

Pump Flow Capacity

21.7 gal/min

Dimensions

Wheelbase

7.2 ft in

Height with ROPS

8.1 ft in
