Case IH Farmall 45C CVT 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
Units

Dimensions

Dimensions

C

Height to Top of Cab

92.72in


Specifications

Drawbar

Description

2-position swinging

Electrical System

Alternator (ROPS)

75rpm

Alternator (CAB)

90amps

System

12V

Engine

Fuel injection

Direct

Fan drive method

Belt

Emissions level

Tier 4B / Final

Exhaust Gas Recirculation (EGR)

Internal EGR

Number of Cylinders

3

Diesel Oxidation Catalyst

DOC standard

Rated engine speed

2600rpm

Advertised Rated Engine Power

45.1hp

Maximum Engine Power

45.1hp

PTO Horsepower

36.3hp

PTO Speed

540rpm

PTO operational Type

Independent

Block Design

Parent bore block

Exhaust Pipe

Horizontal

Engine Make

Case IH FPT

Engine Model

R7531E4

Diesel Particulate Filter

Particulate Matter Catalyst

Fuel tank capacity

13gal

Displacement

136.1cu in

Bore

3.8in

Stroke

4.3in

Aspiration

Wastegate Turbocharger, aftercooled

Alternator

55amps

Fuel system

High Pressure Common Rail

Transmission

Number of Forward / Reverse Speeds

Infinite

shuttle type

Standard

Manufacturers Description

Continuously Variable Transmission

Transmission Type

Chain Variator Drive

Maximum Speed Forward

18.6mph

Weights

Weight without ballast

4938.4lb

Weight 4WD With ROPS

4188.8lb

Tires

Drive Tires

4WD

Steering

Front Steer

Front

10-16.5, 6PR R4

Rear

17.5Lx24, 6PR R4

Hydraulic System

Hydraulic System Type

Open Center

Main pump type

Dual gear

Implement Pump Flow

9.8gal/min

Optional Pump Flow

58.2

Pump Type

Fixed Displacement Gear Pump

Number of Remote Control Valves

1 standard 2nd optional

Axles

Axle Output End

Flange

Final Drive

Inboard or Planetary

3-Point Hitch

Category

1

Lift Capacities - Standard

3540.7lb

Lift capacity @ 24”

2799.9lb

Draft sensing

Position control

Brakes

Service brake

Wet multi disc

Dimensions

Height to top of cab

92.8in

Height to top of ROPS

97.4in

Wheelbase 4WD

73.6in

Overall Width

68.4in

Length, MFD/4WD or track, incl. Hitch/Drawba

122in

`
