Case IH Farmall 35A 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
MODEL.UNITS

Dimensions

Dimensions

D

Wheelbase

5.63ft in

Height (Rops)

876.78in

Length

121.03in

Overall Width

66.5in


Specifications

Drawbar

Description

Category 4, Swinging

Electrical System

System

12V

Alternator

85amps

Engine

Fuel Injection

Indirect

Emissions Level

Tier 4B / Final

Pto Horsepowerbasicgear

30.8hp

Optional Transmission Hst

29hp

Exhaust Gas Recirculation (Egr)

Internal EGR

Number Of Cylinders

3

Diesel Oxidation Catalyst

DOC standard

Advertised Rated Engine Power

36.3hp

Maximum Engine Power

36.3hp

Pto Horsepower

384.9hp

Pto Speed

540rpm

Pto Operational Type

Independent

Block Design

Wet liners

Fuel System Control

Electronic

Steering Configuration

Front Steer

Drive Wheels / Tracks

4 Tracks

Exhaust Pipe

Horizontal

Engine Make

IHI Shibaura

Engine Model

N843T-F

Rated Engine Speed

2600rpm

Diesel Particulate Filter

DPF standard

Fuel Tank Capacity

7.4gal

Displacement

91.3cu in

Bore

3.4in

Stroke

3.6in

Aspiration

Turbocharged

Emission Level

( US EPA Tier)Tier 4B / Final

Fan Drive Type

Belt

Transmission

Shuttle (Forward-Reverse)

Standard

Manufacturers Description

12x12 Gear w/ Synchronized Shuttle

Transmission Type

Synchronized shuttle, gears/ranges non-synch

Number Of Forward Gears

12

Number Of Reverse Gears

12

Max Speed - Forward

14.3mph

Weights

Weight With Maximum Ballast

3867lb

Weight 4wd With Rops

3066.7lb

Tires

Front

25x8.50-14, 6PR R4

Rear

43x16.00-20, 4PR R4

Hydraulic System

Hydraulic System Type

Open center

Main Pump Type

Gear

Axles

Axle Output End

Flange

Hydraulic System

Implement Pump Flow

8.2gal/min

Axles

Final Drive

Inboard Planetary

Hydraulic System

Number Of Remote Control Valves

1 or 2 optional

3-Point Hitch

Lift Capacity At Lift Pin

1807.8lb

Category

1

Lift Capacity @ 24”

1433.1lb

Draft Sensing

Position control

Brakes

Service Brake

Wet disc
