Case IH Axial-Flow 8010 Combine

Case IH Axial-Flow 8010 Combine Specs front
Case IH Axial-Flow 8010 Combine Specs front
Case IH Axial-Flow 8010 Combine Specs side
Case IH Axial-Flow 8010 Combine Specs side
Case IH Axial-Flow 8010 Combine Specs back
Case IH Axial-Flow 8010 Combine Specs back
Units

Dimensions

Dimensions

B

Width Over Tires

13.03 ft in

D

Wheelbase

12.2 ft in


Specifications

Engine

Engine Make

2408

Power

400 hp

Power Boost Power

450 hp

Displacement

628.6 cu in

Operational

Operating Weight w/o Attachment

35500 lb

Fuel Capacity

264 gal

Transmission Type

hydrostatic drive

Number of Gears

4

Threshing

Rotor Diameter

30 in

Rotor Speed - Low

220 rpm

Rotor Speed - High

1180 rpm

Cleaning System

Total Cleaning Area

10695.1 in2

Cleaning Fan Speed - Low

300 rpm

Cleaning Fan Speed - High

1150 rpm

Self Leveling?

Yes

Grain Handling

Grain Tank Capacity

350 bu

Unloading Auger Length

21 ft in

Unloading Speed

3.2 bu/sec

Dimensions

Height to Top of Isomount Cab

12.5 ft in

Width Over Tires

13.1 ft in

Wheelbase

12.2 ft in


Compare similar models

Manufacturer / Model

Power

Operating Weight w/o Attachment

Power

400 hp

Operating Weight w/o Attachment

34832 lb

Power

420 hp

Operating Weight w/o Attachment

35960 lb

Power

370 hp

Operating Weight w/o Attachment

34832 lb
