Case IH AXIAL-FLOW 6140 Combine

Case IH AXIAL-FLOW 6140 Combine Specs front
Case IH AXIAL-FLOW 6140 Combine Specs front
Case IH AXIAL-FLOW 6140 Combine Specs side
Case IH AXIAL-FLOW 6140 Combine Specs side
Case IH AXIAL-FLOW 6140 Combine Specs back
Case IH AXIAL-FLOW 6140 Combine Specs back
Units

Specifications

Engine

Emission Tier Level

Tier 4B / Final

Fuel tank

250 gal

Number of Cylinders

6

Max. horsepower

411 hp

Rated horsepower

348 hp

Piston displacement

531 cu in

Power Boost

63 hp

Engine Make

Case IH FPT

Engine Model

8.7 L

Diesel exhaust fluid (DEF) tank capacity

42.3 gal

Feeding

Feeder Speed Variable

2-speed standard

Feeder Width

45.6 in

Feeder Reverser Control

Electro-Hydraulic

Feeder Tilt Adjustment

Fore-aft standard, Lateral standard.

Stone or Rock Protection

Stone trap

Tires

Reference Drive Tire Size

Dual 520/85 R38, R1

Threshing

Threshing System Type- Rotary or Conventional Cylinder

Longitudinal rotor

Tires

Steering Tire Size

600/65 R28, R1W

Threshing

Number of Rotors or Cylinders

1 Rotor

Rotor or Cylinder Description

Staggered Rasp Bars

Tires

Rubber Tracks Available

No

Threshing

Rotor or Cylinder Diameter

30 in

Rotor or Cylinder Length

110 in

Weights

Weight 2WD-single tires

34129.8 lb

Weight 2WD-dual tires

37130.3 lb

Threshing

Rotor or Cylinder Speed Range

250 to 1150

Threshing Area

156.5 in2

Weights

Wheelbase, 2WD

150.2 in

Threshing

Concave Adjustment

Electric

Weights

Transport Height

13.4 ft in

Cleaning System

Total Sieve Area-Fixed

8556.1 in2

Total Sieve Area-Cross Flow

8370.1 in2

Leveling System Available

Fixed or Cross Flow

Cleaning Fan Description

11.4 (290) dia. Cross Flow In

Cleaning Fan Speed Range

450 to 1300

Grain Handling

Reach from Machine Center- Standard Auger

25.9 ft in

Reach from Machine Center- Optional Auger

21.6 ft in

Grain Tank Capacity

300 bu

Unloading Speed

3.3 bu/sec
