Case IH 790 PLOWING-FOLDING Disc

Disc
Disc
Disc
Disc
Disc
Disc
MODEL.UNITS

Dimensions

Dimensions

Depth Control

Mechanical standard / Hydraulic optional.

Fore -Aft Leveling

Turnbuckle with locking pin

Sizes Available Or Number Of Widths

1

Transport Width- Maximum

15.75ft in

Transport Width-Minimum

15.75ft in

Typical Operating Depth

12.8in

Working Width- Maximum,

21.49ft in

Working Width- Minimum

21.49ft in


Specifications

Gangs

Disk Harrow Type, Tandem Or Offset

Offset

Folding (Multi-Section) Or Non-Folding

Folding

Disk Blade Scraper, Type

Spring type, adjustable

Gang Mounts

Fixed

Gang Arbor Bolts

1.8in

Gang Spool Diameter

8in

Bearing Type

Bolt-on trunnion bearings

Weights

Total Weight- Minimum

16199.6lb

Tires

Transport Wheel Mounting

Two sets of side-by-side tires with axles on rockshaft wheel arms

Weights

Total Weight- Maximum

16199.6lb

Tires

Transport Tires

12.5 x 15FI

Optional Transport Tires

31-13.5 x 15 terra rib

Blade

Disk Blade Spacing

12.1in

Disk Blade Diameter

32.1in

Disk Blade Thickness

0.4in

Blade Edge Profile

Notched

Optional Blade Edge Profile

Smooth
