Case CX40B ZTS Mini Excavator

Case CX40B ZTS Mini Excavator Specs front
Case CX40B ZTS Mini Excavator Specs front
Case CX40B ZTS Mini Excavator Specs side
Case CX40B ZTS Mini Excavator Specs side
Case CX40B ZTS Mini Excavator Specs extended
Case CX40B ZTS Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

16.41 ft in

C

Shipping Height of Unit

8.54 ft in

I

Max Cutting Height

18.02 ft in

J

Max Loading Height

12.83 ft in

K

Max Reach Along Ground

18.57 ft in

L

Max Vertical Wall Digging Depth

8.63 ft in

M

Max Digging Depth

11.13 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

16.41 ft in

C

Shipping Height of Unit

8.54 ft in

I

Max Cutting Height

18.64 ft in

J

Max Loading Height

13.46 ft in

K

Max Reach Along Ground

19.43 ft in

L

Max Vertical Wall Digging Depth

9.55 ft in

M

Max Digging Depth

12.01 ft in

Dimensions

B

Width to Outside of Tracks

6.44 ft in

D

Length of Track on Ground

5.98 ft in

E

Ground Clearance

1.14 ft in

G

Height to Top of Cab

8.54 ft in

H

Tail Swing Radius

3.22 ft in

Undercarriage

F

Track Gauge

5.12 ft in

N

Shoe Size

15.75 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2348

Engine Model

4TNV88A-XYB

Net Power

43 hp

Power Measured @

2400 rpm

Displacement

133.7 cu in

Max Torque

102.8 lb ft

Torque Measured @

1440 rpm

Operational

Operating Weight

9479.9 lb

Fuel Capacity

14.1 gal

Cooling System Fluid Capacity

1.6 gal

Hydraulic System Fluid Capacity

16.7 gal

Engine Oil Capacity

2 gal

Operating Voltage

12 V

Alternator Supplied Amperage

55 amps

Hydraulic System Relief Valve Pressure

3335.9 psi

Hydraulic Pump Flow Capacity

39.1 gal/min

Swing Mechanism

Swing Speed

8.8 rpm

Undercarriage

Shoe Size

15.8 in

Ground Pressure

4 psi

Max Travel Speed

2.7 mph

Track Gauge

5.2 ft in

Buckets

Reference Bucket Capacity

0.2 yd3

Minimum Bucket Capacity

0.2 yd3

Maximum Bucket Capacity

0.3 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Std. Dipper 1.43M

Shipping Height of Unit

8.6 ft in

Shipping Length of Unit

16.5 ft in

Max Digging Depth

11.2 ft in

Max Reach Along Ground

18.6 ft in

Max Cutting Height

18.1 ft in

Max Loading Height

12.9 ft in

Max Vertical Wall Digging Depth

8.7 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Long Dipper 1.70M

Shipping Height of Unit

8.6 ft in

Shipping Length of Unit

16.5 ft in

Max Digging Depth

12.1 ft in

Max Reach Along Ground

19.5 ft in

Max Cutting Height

18.7 ft in

Max Loading Height

13.5 ft in

Max Vertical Wall Digging Depth

9.6 ft in

Dimensions

Width to Outside of Tracks

6.5 ft in

Height to Top of Cab

8.6 ft in

Ground Clearance

1.2 ft in

Removal Counterweight Clearance

2.1 ft in

Tail Swing Radius

3.3 ft in

Length of Track on Ground

6 ft in
